Schneider Electric Q4L3350
MPNQ4L3350
Active
MOLDED CASE CIRCUIT BREAKER 240V 350A|MOLDED CASE CIRCUIT BREAKER 240V 350A
$3,365.00 – $5,510.29Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product or component type | Circuit breaker |
| Line rated current | 350 A |
| Magnetic hold current | 1750 A |
| Breaking capacity code | Q4 |
| Magnetic tripping current | 3500 A |
| Poles | 3P |
| Mounting mode | Unit mount |
| Terminal identifier | AL400LA |
| Electrical connection | Lugs, load Lugs, line |
| Depth | 5.84 in (148.34 mm) |
| Width | 6 in (152.4 mm) |
| Height | 11 in (279.4 mm) |
| Certifications | UL Listed IEC CSA |
| Category | US10DE200933 |
| Tightening torque | 371.7 lbf.in (42 N.m) 0.08...0.5 in² (50...300 mm²) (AWG 1...600 kcmil) 371.7 lbf.in (42 N.m) 0.08...0.2 in² (50...120 mm²) (AWG 1...250 kcmil) |
| Trip unit technology | Thermal-magnetic |
MPN
Q4L3350
