Schneider Electric RE11LHBM

Schneider Electric RE11LHBM

MPNRE11LHBM
Obsolete

Modular Timing Relay

$52.35 – $90.00Ref. price · indicative, final on quote
Schneider Electric RE11LHBM datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

RE11LHBM key specifications
ParameterValue
Control typeSelector switch front panel
Time delay typeH
Range of productZelio Time
Discrete output typeSolid state
Product or component typeModular timing relay
Voltage drift+/- 0.2 %/V
Voltage range0.85...1.1 Us
Surge withstand1 kV differential mode IEC 61000-4-5 level 3 2 kV common mode IEC 61000-4-5 level 3
Maximum voltage drop<8 V 2-wire
Immunity to voltage dips30 % / 10 ms IEC 61000-4-11 60 % / 100 ms IEC 61000-4-11 95 % / 5 s IEC 61000-4-11
Maximum switching voltage250 V
Supply voltage24...240 V AC 50/60 Hz

All specifications

RE11LHBM additional specifications
ParameterValue
Breaking capacity0.5 A AC/DC UL 0.7 A AC/DC 68 °F (20 °C)
Maximum output current20 A
Nominal output current0.7 A
Maximum leakage current5 mA
Minimum switching current10 mA
Power consumption in32 VA 240 V
IP degree of protectionIP20 IEC 60529 terminal block) IP40 IEC 60529 housing) IP50 IEC 60529 front panel)
Mounting support35 mm symmetrical mounting rail conforming to EN 50022
Connections - terminalsScrew terminals, 1 x 4 mm² without cable end Screw terminals, 2 x 1.5 mm² with cable end Screw terminals, 2 x 2.5 mm² without cable end
Relative humidity93 % without condensation IEC 60068-2-3
Vibration resistance0.35 mm (f= 10...55 Hz) conforming to IEC 60068-2-6
Housing materialPolycarbonate
Width pitch dimension0.7 in (17.5 mm)
Electrical durability100000000 cycles
Mechanical durability100000000 cycles
StandardsEN 50081-1/2 73/23/EEC 89/336/EEC 93/68/EEC EN 50082-1/2 IEC 61812-1 IEC 60669-2-3
MarkingCE
Category22370-RE, RM MISC TIMERS & COUNTERS
Reset time350 ms on de-energisation
Component nameRE11L
On-load factor100 %
Derating factor5 mA/°C
Repeat accuracy+/- 0.5 % IEC 61812-1
Time delay range0.1...1 s 1...10 s 10...100 h 6...60 min 1...10 min 1...10 h 6...60 s
Creepage distance4 kV/3 IEC 60664-1
Temperature drift+/- 0.05 %/°C
Dielectric strength2.5 V 1 mA/1 minute IEC 60255-5 2.5 V 1 mA/1 minute IEC 60664
Minimum pulse duration0.05 s
Immunity to microbreaks10 ms
Resistance to fast transients1 kV IEC 61000-4-4 level 3 capacitive connecting clip) 2 kV IEC 61000-4-4 level 3 direct)
Disturbance radiated (conducted)Class B EN 55022 (EN 55011 group 1)
Setting accuracy of time delay+/- 10 % of full scale 25 °C IEC 61812-1
Immunity to radioelectric fields10 V 0.15...80 MHz)ENV 50141 (IEC 61000-4-6 level 3)
Ambient air temperature for storage-22...140 °F (-30...60 °C)
Resistance to electromagnetic fields9.1 V/m (10 V/m) 80 MHz to 1 GHz ENV 50140/204 level 3 9.1 V/m (10 V/m) 80 MHz to 1 GHz IEC 61000-4-3 level 3
Ambient air temperature for operation-4...140 °F (-20...60 °C)
Resistance to electrostatic discharge6 kV in air IEC 61000-4-2 level 3 8 kV in contact IEC 61000-4-2 level 3
