ABB 266HSH.P.S.T.B.3.E2.L1.S2.C5.H3
MPN266HSH.P.S.T.B.3.E2.L1.S2.C5.H3
Gauge Pressure Transmitter
$3,766.00Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product type | Gauge Pressure Transmitters |
| Process connection | T - AISI 316L ss; 1/2 in.-14 NPT male |
| Housing material and electical connection | B - Aluminium alloy(barrel version); M20 x 1.5 (CM 20) |
| Surge | S2 - Surge/Transient Protector |
| Shipping weight | 15 Kg |
| Material traceability | H3 - Inspection certificate EN 10204–3.1 of process wetted parts (not for gaskets) |
| Diaphragm material (Fill fluid (wetted parts)) | S - AISI 316L ss; Silicone oil |
| Hazardous area certifications | E2 - ATEX Explosion Proof Ex db |
| Certificates | C5 - Inspection certificate EN 10204–3.1 of the pressure test |
| Integral LCD | L1 - Digital LCD integral display with integrated keypad |
| Manufacturer | ABB |
| Estimated lead | 6 - 8 weeks. |
| Sensor (span limits) | P - 24 and 2400 kPa; 0.24 and 24 bar; 3.5 and 348 psi |
| Output (Additional options) | 3 - FOUNDATION Fieldbus |
MPN
266HSH.P.S.T.B.3.E2.L1.S2.C5.H3
