4-pole RCD, 40 A rated current, 30 mA residual trip, 10 kA Icn. IP4X face protection. Clamp terminals, 2.8 Nm tightening torque.
| Parameter | Value |
|---|---|
| Overvoltage category | III |
| Parameter | Value |
|---|---|
| Width | 70 mm |
| Height | 85 mm |
| Depth | 69 mm |
| Parameter | Value |
|---|---|
| Poles | 4 |
| Frequency | 50 Hz |
| IP rating | IP2X;IP4X;IPXXB |
| Current | 40 A |
| Terminal contact type | Clamp |
| Tripping fault current | 30 mA |
| Tightening torque - Screw-Type max. | 2.8 Nm |
| Rated Short-Circuit breaking capacity icn | 10 kA |
The F204 A-40/0.03: 4-pole RCD rated 40 A with 30 mA residual trip. 10 kA Icn handles panel-level faults on 50 Hz supplies. IP4X front and IPXXB back-of-hand protection suit it for spray-wash areas in bottling or food lines. Clamp terminals rated for 2.8 Nm torque.
Dimensions 70 mm wide, 85 mm high, 69 mm deep. Overvoltage category III for fixed installation. Screw-clamp terminals accept ring or fork lugs.
30 mA trip sensitivity for personnel protection against ground faults.
IP2X finger protection, IP4X splash protection, IPXXB back-of-hand protection.
