Festo DSL-40-100-270P-S2-FF
MPNDSL-40-100-270P-S2-FF
FESTO 175895 LINEAR UNIT
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Model | DSL-40-100-270P-S2-FF |
Configuration
| Parameter | Value |
|---|---|
| Mode of operation | Double acting |
| Product type | Swivel/Linear Unit |
Dimensions
| Parameter | Value |
|---|---|
| Piston diameter | 40 mm |
| Stroke length | 100 mm |
Pneumatic
| Parameter | Value |
|---|---|
| Operating pressure, max. | 8 bar |
| Pneumatic connection | G1/8 |
Other specifications
| Parameter | Value |
|---|---|
| Weight | 6,5 kg |
| Condition | Used |
| Shelf no. | 250103 |
| Max. swivel angle | 270° |
| Ambient temperature range | -10 to 60 °C |
MPN
DSL-40-100-270P-S2-FF
