NPFC-R-G1-G34-F
Festo
Free Hanging (In-Line)G1, G3/4Straight Fitting
Ref. price$24.40 – $28.83
Lead time on requestGet quote
Festo NPFC Series
140 variants · Festo
About the Festo NPFC Series
The Festo NPFC Series series groups 140 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common connection method of Threaded, material of Nickel Plated Brass and operating pressure of -14 to 725 PSI (-1 to 50 bar). Variants differ by connector size, mounting and product type, so you can match the exact connector size your application requires using the selection guide below.
Select a variant by
- Connector size
- G1 · G1, G3/4 · G1/2 · G1/2, G1 · G3/8 · R1 · R1, G1 · R3/4
- Mounting
- Bulkhead · Free Hanging (In-Line)
- Product type
- Adapter · Elbow Fitting · Straight Fitting · T-Fitting
Shared specifications
- Connection method
- Threaded
- Material
- Nickel Plated Brass
- Operating pressure
- -14 to 725 PSI (-1 to 50 bar)
- Package
- Bulk
- Temp operating max
- 150 °C
- Temp operating min
- -20 °C
Variant comparison
| Parameter | NPFC-R-G1-G34-F | NPFC-T-2G1-R1-FMF | NPFC-T-3G1-F | NPFC-R-G1-G12-F | NPFC-H-G12-F | NPFC-L-2G1-F |
|---|---|---|---|---|---|---|
| Connector size | G1, G3/4 | R1, G1 | G1 | G1/2, G1 | G1/2 | G1 |
| Mounting | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Bulkhead | Free Hanging (In-Line) |
| Product type | Straight Fitting | T-Fitting | T-Fitting | Straight Fitting | Straight Fitting | Elbow Fitting |
Request a quote on any Festo NPFC Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
