Schneider Electric HMIBSCEA53D1L0T

Schneider HMIBSCEA53D1L0T Harmony iPC IIoT Edge Box Core (discontinued)

MPNHMIBSCEA53D1L0T
Obsolete

Schneider HMIBSCEA53D1L0T Square D Relay Module — now discontinued, supplied from remaining surplus and broker stock.

$1,150.00Ref. price · indicative, final on quote
Schneider Electric HMIBSCEA53D1L0T datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

HMIBSCEA53D1L0T key specifications
ParameterValue
Main typeIIoT Edge Box Core
Control typeResettable
Connector type1.0 GPIO Pin, 8 pins bottom(Software utility provided)
Type of coolingFanless
Range of productHarmony iPC
Product or component typeIIoT Edge Box Core
Communication network type1.0 WCN3620 Wi-Fi 2.4 GHz conforming to IEEE 802.11 b/g/n 1.0 WCN3620 Bluetooth 4.1
Supply voltage limits12...24 V
Supply voltage24 V DC power supply 100...240 V AC power supply
Inrush current0.43 A
Mounting locationBook mounting Flat mounting Wall mounting
Electrical connectionScrew connector, connector type: pin, 1 way, circuit application: ground - location: bottom Connector, connector type: SMA - location: top

All specifications

HMIBSCEA53D1L0T additional specifications
ParameterValue
Operating altitude6561.68 ft (2000 m) IEC 60664-1
Width6.2 in (157 mm)
Height5.9 in (150 mm)
StandardsClass A group 1 IEC 55011 IEC 61000-6-4 IEC 61131-2 FCC part 15 UL 60950
CategoryUS10MC222577
Directives2004/108/EC - electromagnetic compatibility 2006/95/EC - low voltage directive
Free slots1 SD card SD 3.0, max raw transfer rate 104 MBps Supports SD,SDHC,SDXC (Standard 32 mm x 24 mm)
Quality labelsCE
Watchdog timer1...255 ms
Number of slots1 slot(s) for mini PCI Express full-size with optional interface plate, 1 slot(s) for M.2 not for storage,
Software packageNode-RED and system nodes default IIoT Wiring
Device short nameIIoT Edge Box Core
Cyber secured bootSecure password boot
Display resolution1920 x 1080 pixels at 60 Hz
Memory description1 GB RAM LPDDR3 internal not expandable)
Accessory (separate part destination)Celullar 4G and analog Inputs
Ambient air temperature for operation32...122 °F (0...50 °C) by default) IEC 60068-2-2 32...122 °F (0...50 °C) flat mounting 32...113 °F (0...45 °C)mini PCIe 32...113 °F (0...45 °C) flat mountingmini PCIe
Number of slots available for expansion1.0 mini PCIe 1.0 M.2 (not for storage)

Product details

Overview

The HMIBSCEA53D1L0T is a Schneider Harmony iPC IIoT Edge Box Core, a fanless edge computing node with integrated 1.0 WCN3620 Wi-Fi 2.4 GHz conforming to IEEE 802.11 b/g/n and Bluetooth 4.1, powered by 24 VDC.
