Schneider Electric LA1LB0311
MPNLA1LB0311
Obsolete
LA1LB0311 - AUXILIARY CONTACT by TELEMECANIQUE
$85.33Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Auxiliary contacts type | Instantaneous 1 NO + 1 NC) control knob in any position other than auto |
| Product or component type | Auxiliary contact |
| Voltage | 690 V IEC 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A |
| Rated operational power in | 120 W 24 V DC-13 1000000 cycles 150 W 48 V DC-13 1500000 cycles 28 W 440 V DC-13 1500000 cycles 33 W 220 V DC-13 1500000 cycles 38 W 110 V DC-13 1500000 cycles 61 W 440 V DC-13 1000000 cycles 68 W 220 V DC-13 1000000 cycles 70 W 24 V DC-13 1500000 cycles 75 W 110 V DC-13 1000000 cycles 90 W 48 V DC-13 1000000 cycles |
| Connections - terminals | 2 screw clamps terminals 0.002 in² (1 mm²) 2 screw clamps terminals 0.004 in² (2.5 mm²) |
| Range | TeSys |
| Category | 22384-STARTERS,INTEGRAL,ACCESS |
| Making capacity | 1500 VA 48 V AC AC-15) 220 W 440 V DC DC-13) 260 W 220 V DC DC-13) 3500 VA 110...127 V AC AC-15) 400 W 110 V DC DC-13) 6000 VA 220...240 V AC AC-15) 700 W 48 V DC DC-13) 7000 VA 440 V AC AC-15) 7500 VA 380...415 V AC AC-15) 800 W 24 V DC DC-13) |
| Device short name | LA1LB |
| Switching capacity in | 0.6 VA >= 17 V 0.01 A |
MPN
LA1LB0311
