A9N18426
Schneider Electric
WhiteIP20Distribution
Ref. price$291.47 – $530.00
Lead time on requestGet quote
Schneider Electric A9N1 Series
124 variants · Schneider Electric
About the Schneider Electric A9N1 Series
The Schneider Electric A9N1 Series series groups 124 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common application of Distribution, color of White and control type of Toggle. Variants differ by electrical life cycles and width, so you can match the exact electrical life cycles your application requires using the selection guide below.
Select a variant by
- Electrical life cycles
- 5000 cycles conforming to IEC 60947-2 · 10000 cycles conforming to IEC 60947-2
- Width
- 27 mm · 54 mm · 81 mm · 108 mm
Shared specifications
- Application
- Distribution
- Color
- White
- Control type
- Toggle
- Depth
- 73 mm
- Height
- 81 mm
- IP rating
- IP20
- Main product or component type
- Miniature circuit-breaker
- Mechanical life cycles
- 20000 cycles
- Operating temperature
- -30...60 °C
- Pollution degree
- 3 conforming to IEC 60947-2
- Storage temperature
- -40...70 °C
- Temp operating max
- 60 °C
Variant comparison
| Parameter | A9N18480 | A9N18426 | A9N18468 | A9N18469 | A9N18512 | A9N18467 |
|---|---|---|---|---|---|---|
| Electrical life cycles | 5000 cycles conforming to IEC 60947-2 | 5000 cycles conforming to IEC 60947-2 | 5000 cycles conforming to IEC 60947-2 | 5000 cycles conforming to IEC 60947-2 | 5000 cycles conforming to IEC 60947-2 | 10000 cycles conforming to IEC 60947-2 |
| Width | 108 mm | 81 mm | 81 mm | 81 mm | 81 mm | 81 mm |
Request a quote on any Schneider Electric A9N1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
