Schneider Electric LADR Series

8 variants · Schneider Electric

About the Schneider Electric LADR Series

The Schneider Electric LADR Series series groups 8 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common color of Dark grey, depth of 2.4 in (61 mm) and height of 1.9 in (48 mm). Variants differ by IP rating and time delay range, so you can match the exact IP rating your application requires using the selection guide below.

Select a variant by

IP rating: IP2X · IP20
Time delay range: 0.3–3 s · 1–30 s · 10–180 s

Shared specifications

Color: Dark grey
Depth: 2.4 in (61 mm)
Height: 1.9 in (48 mm)
Operating temperature: -40...158 °F (-40...70 °C)
Storage temperature: -76...176 °F (-60...80 °C)
Temp operating max: 70 °C
Temp operating min: -40 °C
Temp storage max: 80 °C
Temp storage min: -60 °C
Timer type: Off delay
Width: 1.7 in (44 mm)

Variant comparison

Parameter	LADR4	LADR0	LADR06	LADR23	LADR2
IP rating	IP20	IP20	IP20	IP2X	IP20
Time delay range	10–180 s	0.3–3 s	0.3–3 s	1–30 s	1–30 s

Request a quote on any Schneider Electric LADR Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
