How do the Schneider Electric Schneider Electric LR3D Series variants differ?

Schneider Electric LR3D Series part numbers differ by depth, operating temperature, storage temperature and thermal overload class. Use the selection guide above to pick by depth.

How many Schneider Electric Schneider Electric LR3D Series part numbers are listed?

25 Schneider Electric Schneider Electric LR3D Series part numbers are listed, each with specifications and a datasheet where available.

How do I get pricing and lead time for Schneider Electric Schneider Electric LR3D Series?

Request a quote (RFQ) for any Schneider Electric LR3D Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.

Schneider Electric LR3D Series

25 variants · Schneider Electric

About the Schneider Electric Schneider Electric LR3D Series series

The Schneider Electric Schneider Electric LR3D Series series groups 25 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by depth, operating temperature and storage temperature, so you can match the exact depth your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Schneider Electric LR3D Series variants and discontinued ones from a single page.

Parameter	LR3D016	LR3D1508	LR3D1510	LR3D1512	LR3D1514	LR3D1516
Depth	70 mm	3.6 in (92 mm)	3.6 in (92 mm)	3.6 in (92 mm)	3.6 in (92 mm)	3.6 in (92 mm)
Operating temperature	60 °C	140 °C	140 °C	140 °C	140 °C	140 °C
Storage temperature	70 °C	158 °C	158 °C	158 °C	158 °C	158 °C
Thermal overload class	Class 10 A conforming to IEC 60947-4-1	Class 20 IEC 60947-4-1	Class 20 IEC 60947-4-1	Class 20 IEC 60947-4-1	Class 20 IEC 60947-4-1	Class 20 IEC 60947-4-1
Thermal protection adjustment range	0.1–0.16 A	2.5–4 A	4–6 A	5.5–8 A	7–10 A	9–13 A
Width	45 mm	1.8 in (45 mm)	1.8 in (45 mm)	1.8 in (45 mm)	1.8 in (45 mm)	1.8 in (45 mm)
Height	66 mm	—	—	—	—	—
Terminal pitch	14.5 mm	—	—	—	—	—
