LV433817
4PIP40Special application
Lead time on requestGet quote
Schneider Electric LV43 Series
164 variants · Schneider Electric
Schneider Electric LV43 Molded Case Breakers — TeSys VARIO Load Break Switches and MCCBs
The Schneider LV43 series with over 540 variants encompasses molded case circuit breakers and load break switches in the TeSys VARIO product line, covering 16A to 160A for isolation, switching, and protection in control panels and distribution boards.
Applications
- Machine Main Isolator: Lockable main disconnect on control panels per IEC 60204-1 machine safety requirements.
- Distribution Board Protection: Feeders and sub-circuits in commercial and light industrial electrical distribution.
- Motor Circuit Isolation: Visible isolation gap for motor maintenance per lock-out/tag-out procedures.
Selection
Select by rated current (16A-160A), number of poles (3P, 4P), and function (load break switch vs circuit breaker with thermal-magnetic protection). Padlockable in OFF position for LOTO compliance.
Availability
LV43: broadly stocked at Schneider Electric distributors.
About the Schneider Electric LV43 Series
The Schneider Electric LV43 Series series groups 164 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by main product or component type, application and operating temperature, so you can match the exact main product or component type your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Schneider Electric LV43 Series variants and discontinued ones from a single page.
Select a variant by
- Main product or component type
- Circuit breaker · Interface module · Motor mechanism · Single-end prefabricated cable · Terminal block connector · Trip unit
- Application
- Automatic spring charging · Distribution · Generator
- Operating temperature
- -25...70 °C · -13...158 °F (-25...70 °C) · -4...158 °F (-20...70 °C)
- Storage temperature
- -58...185 °F (-50...85 °C) · -50...85 °C · -40...185 °F (-40...85 °C)
- Temp operating min
- -25 °C · -20 °C
- Temp storage min
- -50 °C · -40 °C
- Poles
- 3P · 4P
- Control type
- By software · Standard · Toggle
Variant comparison
| Parameter | LV434002 | LV434200 | LV434197 | LV432647 | LV430080 | LV430084 |
|---|---|---|---|---|---|---|
| Main product or component type | Interface module | Terminal block connector | Single-end prefabricated cable | Motor mechanism | Trip unit | Trip unit |
| Application | — | — | — | Automatic spring charging | Generator | Generator |
| Operating temperature | -4...158 °F (-20...70 °C) | — | — | — | -25...70 °C | -25...70 °C |
| Storage temperature | -40...185 °F (-40...85 °C) | — | — | — | -50...85 °C | -50...85 °C |
| Temp operating min | -20 °C | — | — | — | -25 °C | -25 °C |
| Temp storage min | -40 °C | — | — | — | -50 °C | -50 °C |
| Poles | — | — | — | — | 3P | 3P |
| Control type | By software | — | — | Standard | — | — |
Request a quote on any Schneider Electric LV43 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
