SICK GTB10-P4212
MPNGTB10-P4212
Optical Sensor PNP 950mm 500us 30VDC 100mA IP67 G10
$108.54 – $125.73Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jun 2026
Specifications
| Parameter | Value |
|---|---|
| Series | G10 |
| Sensor type | Photoelectric Proximity Sensor |
| Parameter | Value |
|---|---|
| Sensing distance, max. | 950 mm |
| Sensing distance, min. | 20 mm |
| Response time | 500 us |
| Light type | LED, Red |
| Parameter | Value |
|---|---|
| Operating voltage, min. | 10 VDC |
| Operating voltage, max. | 30 VDC |
| Parameter | Value |
|---|---|
| Output type | PNP |
| Load current | 100 mA |
| Switching type | Light-ON / Dark-ON |
| Parameter | Value |
|---|---|
| Termination type | Connector, M12, 4-Pin |
| Parameter | Value |
|---|---|
| Protection rating (IP) | IP67 |
| Operating temperature, min. | -30 °C |
| Operating temperature, max. | 60 °C |
| Parameter | Value |
|---|---|
| Length | 39 mm |
| Width | 20 mm |
| Height | 50 mm |
MPN
GTB10-P4212
