SICK IM1808NPSZC1
MPNIM1808NPSZC1
SICK IM18-08NPS-ZC1 INDUCTIVE PROXIMITY SENSOR
$55.00Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
| Parameter | Value |
|---|---|
| Enclosure_material | Metal, Nickel-plated brass |
| Mounting | Non-flush mountable |
| Connector size | M18 x 1 |
| Connector_type | M12 male connector, 4 pin |
| Operating temperature high | -25 … 70 °C |
| Housing_material | Cylindrical thread |
| Length | 64 mm |
| IP rating | IP67 |
| Diameter | 18 |
| Frequency | 600 |
| Product type | INDUCTIVE PROXIMITY SENSOR |
| Thread diameter | M18 x 1 |
All specifications+7 ▾
| Parameter | Value |
|---|---|
| Output_function | Normally open |
| Supply voltage | 30 |
| Power consumption | 10 mA |
| Switching current | 0.02 |
| Switching_output_type | PNP |
| Sensing distance max | 8 |
| Time delay before availability | ≤ 100 ms |
MPN
IM1808NPSZC1
