SICK WL4S-3P2230
MPNWL4S-3P2230
Photoelectric Sensor PNP 4m 500us 30VDC 100mA LED, Red Connector, M8, 4-Pin IP69K W4S-3
$110.49 – $157.98Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Series | W4S-3 |
| Sensor type | Photoelectric Retro-Reflective Sensor |
Sensing
| Parameter | Value |
|---|---|
| Sensing distance, max. | 4 m |
| Sensing distance, min. | 0 m |
| Response time | 500 us |
| Light type | LED, Red |
Electrical
| Parameter | Value |
|---|---|
| Operating voltage, min. | 10 VDC |
| Operating voltage, max. | 30 VDC |
Output
| Parameter | Value |
|---|---|
| Output type | PNP |
| Load current | 100 mA |
| Switching type | Light-ON / Dark-ON |
Connection
| Parameter | Value |
|---|---|
| Termination type | Connector, M8, 4-Pin |
Environmental
| Parameter | Value |
|---|---|
| Protection rating (IP) | IP69K |
| Operating temperature, min. | -30 °C |
| Operating temperature, max. | 70 °C |
Mechanical
| Parameter | Value |
|---|---|
| Length | 45 mm |
| Width | 15 mm |
| Height | 22 mm |
MPN
WL4S-3P2230
