The SICK WT27-2F410 is a photoelectric proximity sensor with a PNP switching output and a sensing range of 100 to 1500 mm, configurable for light-on or dark-on operation. It operates on 10-30 V DC and connects via an M12 4-pin connector, making it a direct-fit replacement in many standard industrial sensor mounts. Rated for -40 to 60 °C ambient, the plastic housing suits indoor conveyor and material-handling zones where ambient temperature stays within that band.
SICK WT27-2F410 Photoelectric Proximity Sensor, PNP, 100-150
MPNWT27-2F410
SICK WT27-2F410, Photoelectric Proximity Sensor, PNP, 100-1500 mm range, 10-30 V DC, M12 4-pin, Light on / Dark on.
$29.50Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Model | WT27-2F410 |
| Parameter | Value |
|---|---|
| Type | Photoelectric Proximity Sensor |
| Parameter | Value |
|---|---|
| Operating voltage range | 10 … 30 V DC |
| Parameter | Value |
|---|---|
| Connection | M12 |
| Parameter | Value |
|---|---|
| Operating temperature range | -40 … 60°C |
| Parameter | Value |
|---|---|
| Material | Plastic |
| Parameter | Value |
|---|---|
| Sensing Range | 100 … 1500 mm |
| Electrical Design | PNP |
| Switching Mode | Light on / Dark on |
| Connector type | M12,4-pin |
| No. of Pin | 4 |
| Condition | Used |
| Parameter | Value |
|---|---|
| Switch Output | PNP |
Product details
Frequently asked questions
What is the sensing range of the WT27-2F410?
The sensing range is 100 to 1500 mm, adjustable within that band for the application.
What output type does the WT27-2F410 use?
It uses a PNP switching output, configurable for light-on or dark-on operation.
MPN
WT27-2F410
