Siemens 3SE5 Series
852 variants · Siemens
Siemens 3SE5 — SIRIUS Safety Position Switch with Separate Actuator for Guard Door Monitoring
The Siemens 3SE5 series is a safety position switch with separate actuator, designed for monitoring the position of movable guards (doors, covers, hoods) on machinery. With over 850 variants, the 3SE5 is the safety-rated interface between the physical guard and the safety controller (3SK or safety PLC), ensuring the machine cannot operate when the guard is open.
How Position Switches Enable Machine Safety
A safety position switch consists of a switch body (mounted on the fixed frame) and a separate actuator (mounted on the movable guard). When the guard closes, the actuator enters the switch head and operates the positively-driven contacts. The positive-drive mechanism ensures that when the contacts open, they are physically forced apart — a welded contact cannot leave the safety circuit falsely closed. This meets the requirements of ISO 14119 for interlocking devices associated with guards.
Key Specifications
| Parameter | Options |
|---|---|
| Actuator type | Standard, hinged, flexible, coded (RFID) |
| Contacts | 1NC+1NO, 2NC, 3NC, 2NC+1NO |
| Enclosure rating | IP65, IP67 |
| Housing material | Plastic or metal |
| Safety integrity | Up to SIL 3 / PL e (with suitable safety controller) |
Availability
3SE5 position switches: broadly stocked. Standard plastic housing with straight actuator: distributor inventory.
About the Siemens 3SE5 Series
The Siemens 3SE5 Series series groups 852 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by cable entry type and circuit principle, so you can match the exact cable entry type your application requires using the selection guide below.
Select a variant by
- Cable entry type
- 1x (M20 x 1.5) · 3x (M20 x 1.5)
- Circuit principle
- slow-action contacts · snap-action contacts
Variant comparison
| Parameter | 3SE5000-0AA01 | 3SE5322-1SD21 | 3SE5312-0SE11 | 3SE5322-0SD21 | 3SE5322-0SE21 | 3SE5112-OCA00 |
|---|---|---|---|---|---|---|
| Cable entry type | — | 3x (M20 x 1.5) | 3x (M20 x 1.5) | 3x (M20 x 1.5) | 3x (M20 x 1.5) | — |
| Circuit principle | — | slow-action contacts | slow-action contacts | slow-action contacts | slow-action contacts | — |
