Omron E2E2-X18MY1-US — Proximity Sensors

Omron E2E2-X18MY1-US M30 Unshielded, 18mm

MPNE2E2-X18MY1-US

Omron E2E2 series, M30 threaded unshielded inductive proximity sensor, 18mm sensing distance, 2-wire AC NO output, 300mA max load, 20-264VAC supply, IP67, 2m prewired cable.

$211.62 – $273.66Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

E2E2-X18MY1-US — Identification
ParameterValue
SeriesE2E2
E2E2-X18MY1-US — Sensing
ParameterValue
Sensing distance, max. (alt.)18 mm
Sensing methodInductive
Sensing-face shieldingUnshielded
E2E2-X18MY1-US — Electrical
ParameterValue
Supply voltage20-264V AC ; Not Rated
AC supply voltage rating20-264V AC
DC supply voltage ratingNot Rated
Number of wires2
Electrical connectionBare Wire
Electrical installation typePrewired Cable
E2E2-X18MY1-US — Output
ParameterValue
Output circuit contact formNO
Output circuit typeAC-Type
Includes indicator lightsIndicator Lights Included
Output circuit2-Wire AC
E2E2-X18MY1-US — Mechanical
ParameterValue
Body styleCylindrical
Overall height65 mm
Body materialBrass
E2E2-X18MY1-US — Environmental
ParameterValue
Operating temperature, max. (alt.)185 °F
Operating temperature, min. (alt.)-40 °F
IP ratingIP67
E2E2-X18MY1-US — Approvals
ParameterValue
Standards / certificationsCCC; CE

Product details

The Omron E2E2-X18MY1-US is an M30 threaded unshielded inductive proximity sensor rated for 18 mm sensing distance with a 2-wire AC normally-open output handling up to 300 mA load across a 20–264 VAC supply range. The prewired 2 m cable terminates bare for field wiring. Mounting hardware and a cable protector with a milled section for wrench grip are included; the indicator light confirms target detection.

Why the 5 mA minimum load is the real constraint

The 2-wire AC output circuit requires a load current between 5 mA and 300 mA for reliable operation.

Peer check: E2E-X2Y2 is not a candidate

The E2E-X2Y2 is a shielded M12 sensor with a 2 mm sensing distance, NC output, and 100 mA max – fundamentally different mounting diameter (M12 vs M30), shielding type (shielded vs unshielded), output logic (NC vs NC vs NO? actually E2E2 is NO as per, and E2E-X2Y2 is NC per output circuit contact form NC), and sensing reach. It is not a physical or functional substitute for this M30 unshielded NC? no, NO) application.

Frequently asked questions

What are the key specifications of the Omron E2E2-X18MY1-US?

M30 threaded unshielded inductive proximity sensor, 18 mm sensing distance, 2-wire AC NO output rated 300 mA max / 5 mA min load, 20–264 VAC supply, IP67, 2 m prewired cable with bare ends, nickel-plated brass body. Operating temperature -40 to 185°F.

Is the sensor shielded or unshielded?

Unshielded per the sensing face shielding field. The entire 18 mm rated sensing distance is available without derating for flush mounting.

Does the E2E-X2Y2 work as a drop-in replacement?

No. The E2E-X2Y2 is a shielded M12 sensor with a 2 mm sensing distance and NC output. This E2E2 is an unshielded M30 with 18 mm range and NO output. Physically incompatible and different electrical logic.

How do you wire a 2-wire AC proximity sensor?

Connect one wire to line (L) and the other to the load; the other side of the load goes to neutral (N). The sensor is normally open so it closes when metal is present. Ensure the load current stays between 5 mA and 300 mA.
