If you're cross-checking against the E2KQ-X10ME1, note that part is a capacitive sensor with a plastic body and a longer 6–10 mm adjustable range. Different detection principle — E2KQ sees non-metallics too — so it's not a mechanical swap. The E2C-X1R5AH is also inductive but in a heat-resistant M8 brass body with a much shorter 1.5 mm range. For a panel originally wired for E2FQ-X5D1, either alternate requires rewiring and a deviation from the approved manufacturer list if Omron is the specified brand.
Omron E2FQ-X5D1 Chemical Resistant Proximity Sensor, M18, 4m
MPNE2FQ-X5D1
Omron E2FQ-X5D1 Chemical-Resistant Inductive Proximity Sensor, M18 metal cylindrical, 4 mm sensing range, 12-24 VDC N.O., cable connector.
$120.65Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Type | Chemical Resistant Proximity Sensor |
Output
| Parameter | Value |
|---|---|
| Switching output | Normally open |
Mechanical
| Parameter | Value |
|---|---|
| Housing material | Metal |
Environmental
| Parameter | Value |
|---|---|
| Operating temperature range | -25 … 70°C |
Other specifications
| Parameter | Value |
|---|---|
| Model | E2FQ-X5D1 |
| Weight | 0,16 kg |
| Housing | Cylindrical |
| Condition | New |
| Shelf no. | 230105 |
| Dimensions | M18 |
| Sensing distance | 0 …. 4 mm |
| Connector type | Cable |
| Sensing object | Ferrous metal |
| Operating voltage | 12 … 24 V DC |
Product details
MPN
E2FQ-X5D1
