Omron E3Z-G61 2M — Photoelectric Sensors

Omron E3Z-G61 2M, Infrared LED, 25mm Gap, NPN

MPNE3Z-G61 2M

Omron E3Z-G61 2M, Grooved-Type Through-Beam Photoelectric Sensor, Built-in Amplifier, Infrared LED, 0 to 25 mm Gap, 2m Pre-wired Cable, NPN Output.

$86.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

E3Z-G61 2M — Sensing
ParameterValue
Sensing distance0mm to 25mm
Light sourceInfrared LED
E3Z-G61 2M — Other specifications
ParameterValue
Connection methodPre-wired models Cable length: 2 m
Control output (Output type)NPN open collector output
Pre-wired models(2m)Sensing methodGrooved type through-beam

Product details

The Omron E3Z-G61 2M is a current-production grooved-type (fork) through-beam sensor with built-in amplifier — no external controller needed. It ships pre-wired with a 2 m cable, so the kit is complete for a direct install into a 25 mm maximum gap application. The output is NPN open collector, and the light source is an infrared LED.

How It Stacks Against E3SGS3E4

The Omron E3SGS3E4 fork sensor offers a 30 mm gap with selectable Light-ON/Dark-ON, NPN output, and a 2 m pre-wired cable. The E3Z-G61 has a 25 mm maximum gap and no selectable operation mode, making it a fixed-logic alternative for gaps under 25 mm.

Frequently asked questions

What is the closest functional alternative to the E3Z-G61 2M?

The Omron E3SGS3E4 is a fork sensor with a 30 mm gap, also NPN and pre-wired 2 m. It offers selectable Light-ON/Dark-ON, whereas the E3Z-G61 2M's operation mode is not listed as selectable.

MPN
E3Z-G61 2M
