Schneider 140-CPS-124-00C Plc Expansion Modules — now discontinued, supplied from remaining surplus and broker stock.
| Parameter | Value |
|---|---|
| Series | Modicon Quantum automation platform |
| Range of product | Modicon Quantum automation platform |
| Voltage out | 5.1 V DC |
| Current in | 1100 mA 115 V 600 mA 230 V |
| Current out | 8 A 140 °F (60 °C) redundant |
| Altitude max | <= 16404.2 ft (5000 m) |
| Humidity max | 95 |
| Standards | CSA C22.2 No 142 UL 508 |
| Marking | CE |
| Power | Redundant |
| Package_type | PCE |
| Module_format | Standard |
| Parameter | Value |
|---|---|
| Resistance | 4 kV contact IEC 801-2 8 kV on air IEC 801-2 |
| Input voltage | 115 |
| Voltage | Internal |
| Local signalling | 1 LED (green) for power (PWR OK) |
| Harmonic distortion | <= 10 % of fundamental rms value |
| Switching current | 19 |
| Storage temperature | -40...185 °F (-40...85 °C) |
| Protective treatment | Conformal coating Humiseal 1A33 |
| Has_local_signalling | 1 LED (green) for power (PWR OK) |
| Associated fuse rating | 2 A, slow-blow |
| Output overload protection | Internal |
| Main_product_or_component_type | Power supply module |
| Operating temperature | 32 |
| Ordering and shipping details (Category) | 18155-QUANTUM I/O & POWER SUPPLIES |
The 140-CPS-124-00C is a redundant power supply module for the Modicon Quantum automation platform, delivering 8 A at 5.1 V DC from a 115 V AC input. It carries CE, cUL, and FM Class 1 Division 2 certifications, with conformal coating and internal output overload protection.
Schneider discontinued the 140-CPS-124-00C on 2026-02-23. Send an RFQ to confirm available quantity and lead time for line-down or last-time-buy needs.
