Schneider Electric 29412
MPN29412
Obsolete
voltage release Compact MN - 48 V DC
$28.98Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Product / component type | Voltage release |
| Device application | Control |
| Parameter | Value |
|---|---|
| Device short name | MN |
| Parameter | Value |
|---|---|
| Range | ComPact |
| Response time | < 50 ms |
| Range of product | NR400...630 NS100...250 DC NR100...250 NB400...600 NS100...250 NSJ400...600 NS400...630 DC NSF150...250 NS400...630 NS125E |
| Operating threshold | 0.35...0.7 x Un opening 0.85 Un closing |
| Supply holding power | < 5 W |
| Voltage release type | Undervoltage release |
| Coil voltage | 48 V DC |
| Auxiliary connection terminal | screw terminal 0...0.002 in² (0...1.5 mm²) |
MPN
29412
