Schneider Electric 60188
MPN60188
Obsolete
Multi9 - C60 UL489 - MCB - 3P - 4 A - D Curve - 240 V - 10 kA - tunnel term
StockContact for availability
Lead timeCall for availability wk
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Product / component type | Miniature circuit-breaker |
| Product name | Multi9 C60 |
| Product range | Multi9 |
| Device application | Distribution |
Electrical
| Parameter | Value |
|---|---|
| Network type (AC/DC) | AC |
| Rated operational voltage [Ue] | 415 V AC 240 V AC 440 V AC |
| Rated insulation voltage [Ui] | 500 V AC EN/IEC 60947-2 |
| Rated impulse withstand voltage [Uimp] | 6 kVEN/IEC 60947-2 |
| Network frequency | 50/60 Hz |
| Poles description | 3P |
| Magnetic tripping limit | 12 x In +/- 20 % AC |
Protection & Performance
| Parameter | Value |
|---|---|
| Breaking capacity | 6 kA Icu 440 V AC EN/IEC 60947-2 10 kA Icu 415 V AC EN/IEC 60947-2 20 kA Icu 240 V AC EN/IEC 60947-2 6 kA Icu 440 V AC GB 14048.2 10 kA Icu 415 V AC GB 14048.2 20 kA Icu 240 V AC GB 14048.2 10 kA AIR 240 V AC UL 489 10 kA AIR 240 V AC CSA C22.2 No 5.2 |
| Trip unit technology | Thermal-magnetic |
| Suitability for isolation | Yes EN/IEC 60947-2 |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles |
| Local signalling | ON/OFF indication |
| Contact position indicator | Yes |
Mechanical
| Parameter | Value |
|---|---|
| Connections / terminals | Tunnel type terminal top or bottom) 0.004...0.04 in² (2.5...25 mm²) AWG 14...AWG 4) - rigid |
| Device short name | C60 UL489 |
| Control type | Toggle |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| Usable 9 mm pitches | 6 |
| Width | 2.1 in (54 mm) |
| Height | 4.2 in (107 mm) |
| Depth | 2.9 in (73 mm) |
Environmental
| Parameter | Value |
|---|---|
| IP degree of protection | IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529 |
| Pollution degree | 3 EN/IEC 60947-2 |
| Operating ambient air temperature | -22...158 °F (-30...70 °C) |
| Storage ambient air temperature | -40...176 °F (-40...80 °C) |
Approvals
| Parameter | Value |
|---|---|
| Standards | GB 14048.2 EN/IEC 60947-2 UL 489 CSA C22.2 No 5 |
Specifications
| Parameter | Value |
|---|---|
| Curve code | D |
| Number of protected poles | 3 |
MPN
60188
