Schneider Electric A9A26946
MPNA9A26946
Active
A9A26946 - ACTI9 by SQUARE D
$33.02Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | Acti9 |
| Product or component type | Shunt trip release with OC contact |
| Coil voltage | 100...415 V AC 50/60 Hz 110...130 V DC |
| Current | AC-12 3 A at 415 V, AC 50 Hz AC-12 6 A at 100 V, AC 50 Hz AC-12 6 A at 230 V, AC 50 Hz DC-12 1 A at 110 V, DC DC-12 1 A at 130 V, DC |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| Connections - terminals | Clamp terminal - 2 cable(s) 2.5 mm² - flexible with cable end Clamp terminal - 1 cable(s) 6 mm² - rigid Clamp terminal - 2 cable(s) 2.5 mm² - rigid Clamp terminal - 1 cable(s) 4 mm² - flexible |
| Relative humidity | 95 % at 55 °C |
| Width | 18 mm |
| Color | White |
| Standards | EN/IEC 60947-1 EN/IEC 60947-5-1 |
| 9 mm pitches | 2 |
All specifications
| Parameter | Value |
|---|---|
| Tropicalisation | 2 conforming to EN/IEC 60947-5-1 |
| Local signalling | Action indicator |
| Device short name | iMX+OF |
| Tightening torque | 1 N.m |
| Signal contacts composition | 1 C/O |
| Ambient air temperature for storage | -40...85 °C |
| Ambient air temperature for operation | -35...70 °C |
| Comb busbar and distribution block compatibility | Top: YES |
MPN
A9A26946
