Overview
The A9XPH224 is a Schneider Acti9 comb busbar rated 100 A at 415 V AC, built to EN/IEC 61439-1, with 2 poles marked N L and 24 modules of 18 mm pitch. It carries IP20 finger protection, is cuttable to length, and fits Acti9 iC60, iK60, iID, iSW, and Multi9 C60 ranges.
Sizing and layout
The busbar spans 24.0 m in length and 429.26 mm in width, with 48 pitches at 9 mm — enough for 12 ways N + 1 L at 0.7 in (18 mm) terminal pitch. Compared to the 3-pole A9XPH312 ( L3, 24 pitches), the A9XPH224 serves single-phase or split-phase panels where only N and L are distributed.
Schneider lists the A9XPH224 as active — no end-of-life notice; lead time is confirmed per RFQ.
