Schneider Electric ABL8BPK24A03

Schneider ABL8BPK24A03 Phaseo battery module, 3.2 Ah, 24 V DC

MPNABL8BPK24A03
Obsolete

Schneider Electric Phaseo ABL8BPK24A03 battery module, Lead-Acid, 3.2 Ah, 24 V DC output, 32 A, IP10, screw terminals, CE, CTP UL.

$78.74Ref. price · indicative, final on quote
Schneider Electric ABL8BPK24A03 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

ABL8BPK24A03 key specifications
ParameterValue
Range of productPhaseo
Output protection typeAgainst overload and short-circuits, protection technology: 1 x 20 A automotive type fuse
Product or component typeBattery module
Input voltage24 V DC
Output voltage24 V DC
Input voltage limits21...29 V
Load current0.3 A
Maximum output current32 A
IP degree of protectionIP10 conforming to IEC 60529
Connections - terminalsFor input connection: screw type terminals, connection capacity: 2 x 0.5...2 x 10 mm² AWG 20...AWG 8 For output connection: screw type terminals, connection capacity: 2 x 0.5...2 x 10 mm² AWG 20...AWG 8
Operating altitude2000 m
Vibration resistance2 gn (f= 11.9...150 Hz) conforming to IEC 61131-2 3.5 mm (f= 3...11.9 Hz) conforming to IEC 61131-2

All specifications

ABL8BPK24A03 additional specifications
ParameterValue
MarkingCE
Fixing modeBy 2 screws diameter: 5 mm on horizontal panel, operating position: horizontal By 4 screws diameter: 5 mm on vertical panel, operating position: vertical By clips (with mounting kit) on 35 mm symmetrical DIN rail, operating position: horizontal By clips (with mounting kit) on 35 mm symmetrical DIN rail, operating position: vertical
Holding time< 20 h at 0.16 A, 20 °C > 5 min at 8.4 A, 20 °C
Charging time72 h
Output couplingParallel
Battery capacity3.2 Ah
Self-discharge rate9 %, 3 months 3 %, 1 month 15 %, 6 months
Overvoltage categoryClass 3 conforming to VDE 0106-1
Service life in hours11000 h at 40 °C 15000 h at 35 °C 22000 h at 30 °C 31000 h at 25 °C 44000 h at 20 °C 5000 h at 50 °C 7300 h at 45 °C
Ambient air temperature for storage-20...50 °C
Ambient air temperature for operation0...40 °C

Product details

Overview

The ABL8BPK24A03 is a Schneider Phaseo battery module delivering 24 V DC from a 3.2 Ah Lead-Acid cell, rated for 32 A continuous output with a 20 A automotive fuse protecting against overload and short-circuits. It carries CE and CTP UL certifications, is sealed to IP10, and mounts via screws or DIN-rail clips; the module is discontinued with last-time-buy available through 2025-12-31.

Selection vs ABL8BPK24A12

The ABL8BPK24A03 holds 3.2 Ah versus the ABL8BPK24A12's 12 Ah; the ABL8BPK24A12 also uses dual 30 A fuses instead of the single 20 A fuse here.
