Schneider Electric BCH0401O12F1C
MPNBCH0401O12F1C
Obsolete
BCH0401O12F1C by SQUARE D
$1,193.33Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Feedback type | 20 bits incremental encoder |
| Type of cooling | Natural convection |
| Product or component type | Servo motor |
| Supply voltage | 220 V |
| Continuous stall current | 0.9 A |
| Continuous power | 0.1 kW |
| Brake pull-in power | 7.3 W |
| Network number of phases | Single phase |
| IP degree of protection | IP40 |
| Mounting support | Asian standard flange |
| Mounting holes diameter | 4.5 mm |
| Number of mounting holes | 4 |
All specifications
| Parameter | Value |
|---|---|
| Circle diameter of the mounting holes | 46 mm |
| Key width | 3 mm |
| Centring collar depth | 2.5 mm |
| Length | 136.6 mm |
| Shaft end | Keyed |
| Second shaft | Without second shaft end |
| Shaft length | 20 mm |
| Holding brake | With |
| Rotor inertia | 0.04 kg.cm² |
| Holding torque | 0.3 N.m |
| Shaft diameter | 8 mm |
| Torque constant | 0.36 N.m/A |
| Back emf constant | 13.6 V/krpm at 20 °C |
| Device short name | BCH |
| Motor flange size | 40 mm |
| Stator inductance | 48 mH at 20 °C |
| Stator resistance | 18.6 Ohm at 20 °C |
| Maximum axial force fa | 39.2 N |
| Number of motor stacks | 1 |
| Maximum radial force fr | 78.4 N |
| Centring collar diameter | 30 mm |
| Maximum mechanical speed | 5000 rpm |
| Distance shaft shoulder-flange | 20 mm |
| Stator electrical time constant | 2.58 ms at 20 °C |
| Ambient air temperature for operation | 0...40 °C |
MPN
BCH0401O12F1C
