Schneider Electric BCH1304N12A1C
MPNBCH1304N12A1C
Obsolete
Servo Motor BCH
$761.00 – $1,438.86Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Feedback type | 20 bits incremental encoder |
| Type of cooling | Natural convection |
| Range of product | Lexium 23 Plus |
| Product or component type | Servo motor |
| Supply voltage | 220 V |
| Continuous stall current | 11.01 A |
| Continuous power | 2 kW |
| Brake pull-in power | 19 W |
| Network number of phases | Three phase |
| IP degree of protection | IP40 |
| Mounting support | Asian standard flange |
| Mounting holes diameter | 9 mm |
All specifications
| Parameter | Value |
|---|---|
| Number of mounting holes | 4 |
| Circle diameter of the mounting holes | 145 mm |
| Key width | 8 mm |
| Product weight | 7.8 kg |
| Centring collar depth | 6 mm |
| Length | 187.5 mm |
| Shaft end | Keyed |
| Second shaft | Without second shaft end |
| Shaft length | 47 mm |
| Holding brake | Without |
| Rotor inertia | 14.59 kg.cm² |
| Shaft diameter | 22 mm |
| Torque constant | 0.87 N.m/A |
| Back emf constant | 31.8 V/krpm at 20 °C |
| Device short name | BCH |
| Motor flange size | 130 mm |
| Stator inductance | 5.52 mH at 20 °C |
| Stator resistance | 0.348 Ohm at 20 °C |
| Maximum axial force fa | 98 N |
| Number of motor stacks | 4 |
| Maximum radial force fr | 490 N |
| Centring collar diameter | 110 mm |
| Maximum mechanical speed | 3000 rpm |
| Distance shaft shoulder-flange | 47 mm |
| Stator electrical time constant | 15.86 ms at 20 °C |
| Ambient air temperature for operation | 0...40 °C |
MPN
BCH1304N12A1C
