Overview
The GS1AN11G is a Schneider TeSys GS auxiliary contact block with 1NC+1NO instantaneous contacts rated for 20 A switching current, designed for right-side mounting on a GS2 switch-disconnector-fuse with a left-side operating handle.
Schneider GS1AN11G TeSys GS auxiliary contact, 1NC+1NO, 20 A, discontinued
MPNGS1AN11G
Obsolete
Schneider GS1AN11G Auxiliary Contacts — now discontinued, supplied from remaining surplus and broker stock.
$52.07Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Fuse type | BS NFC DIN |
| Range of product | TeSys |
| Contact operation | Instantaneous |
| Device short name | GS1AN |
| Contact application | O and I position signalling |
| Switch rated current | 200 A 630 A 50 A 125 A 160 A 315 A 400 A 600 A 800 A 100 A 250 A 60 A 1250 A 63 A |
| Electrical durability | 30000 cycles AC-15 |
| Mechanical durability | 30000 cycles |
| Type of operating handle | External left side |
| Product or component type | Auxiliary contact |
| Contacts type and composition | 1 NC + 1 NO |
| [Ie] rated operational current | 1 A 220 V DC-13 10 A 230 V AC-15 12 A 127 V AC-15 4 A 48 V DC-13 6 A 440 V AC-15 8 A 400/415 V AC-15 1.2 A 110 V DC-13 |
| [Ith] conventional free air thermal current | 20 A (at 104 °F (40 °C)) |
Product details
MPN
GS1AN11G
