Schneider Electric GV2LE08

GV2LE08 TeSys GV2 Motor Circuit Breaker 4A 3P

MPNGV2LE08
Obsolete

Schneider Electric TeSys GV2 motor circuit breaker, GV2LE08, 4 A rated current, 3 poles, dark grey.

$18.52Ref. price · indicative, final on quote
Schneider Electric GV2LE08 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

GV2LE08 key specifications
ParameterValue
Control typeToggle
Network typeAC
Product or component typeMotor circuit breaker
Climatic withstandIACS E10
Voltage690 V AC 50/60 Hz IEC 60947-2
[Ue] rated operational voltage690 V AC 50/60 Hz IEC 60947-2
[Uimp] rated impulse withstand voltage6 kV IEC 60947-2
Breaking capacity100 kA Icu 230/240 V AC 50/60 Hz IEC 60947-2 100 kA Icu 400/415 V AC 50/60 Hz IEC 60947-2 100 kA Icu 440 V AC 50/60 Hz IEC 60947-2 100 kA Icu 500 V AC 50/60 Hz IEC 60947-2 3 kA Icu 690 V AC 50/60 Hz IEC 60947-2
Line rated current4 A
Magnetic tripping current74 A
[Ith] conventional free air thermal current4 A IEC 60947-2
[Ics] rated service short-circuit breaking capacity100 % 230/240 V AC 50/60 Hz IEC 60947-2 100 % 400/415 V AC 50/60 Hz IEC 60947-2 100 % 440 V AC 50/60 Hz IEC 60947-2 100 % 500 V AC 50/60 Hz IEC 60947-2 75 % 690 V AC 50/60 Hz IEC 60947-2

All specifications

GV2LE08 additional specifications
ParameterValue
Motor power1.5 kW 400/415 V AC 50/60 Hz 1.5 kW 500 V AC 50/60 Hz 2.2 kW 500 V AC 50/60 Hz 3 kW 690 V AC 50/60 Hz
Power dissipation per pole1.8 W
Network frequency50/60 Hz IEC 60947-2
Poles description3P
Rated dutyUninterrupted IEC 60947-4-1
Utilisation categoryCategory A IEC 60947-2 AC-3 IEC 60947-4-1 AC-3e IEC 60947-4-1
IK degree of protectionIK04
IP degree of protectionIP20 IEC 60529
Mounting positionHorizontal Vertical
Connections - terminalsPower circuit screw clamp terminal 2 0.002...0.009 in² (1...6 mm²)solid Power circuit screw clamp terminal 2 0.002...0.009 in² (1.5...6 mm²)flexible without cable end Power circuit screw clamp terminal 2 0.002...0.006 in² (1...4 mm²)flexible with cable end
Operating altitude<= 6561.68 ft (2000 m)
ColorDark grey
Depth3.09 in (78.5 mm)
Width1.8 in (45 mm)
Height3.5 in (89 mm)
Electrical durability100000 cycles AC-3 415 V In 100000 cycles AC-3e 415 V In
Mechanical durability100000 cycles
StandardsEN/IEC 60947-2 EN/IEC 60947-4-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 IEC/EN 60335-2-40:Annex JJ
RangeTeSys Deca
CategoryUS1CP1018402
Fixing mode35 mm symmetrical DIN rail clipped Panel screwed with adaptor plate)
Fire resistance1760 °F (960 °C) IEC 60695-2-11
Device short nameGV2LE
Tightening torque15.05 lbf.in (1.7 N.m) screw clamp terminal
Device applicationMotor protection
Trip unit technologyMagnetic
Mechanical robustnessShocks 30 Gn for 11 ms Vibrations 5 Gn, 5...150 Hz
Suitability for isolationYes IEC 60947-1
Ambient air temperature for storage-40...176 °F (-40...80 °C)
Ambient air temperature for operation-4...140 °F (-20...60 °C)

Product details

GV2LE08 – Motor circuit breaker, 4 A, 3-pole

The GV2LE08 is a 3-pole motor circuit breaker from the TeSys GV2 range, rated 4 A continuous for motor protection. Magnetic trip set at 74 A provides instantaneous short-circuit interruption. Designed for AC-3 and AC-3e duty (motor starting/switching) and certified as a disconnecting means per IEC 60947-1.

The 4 A continuous rating sets the maximum steady-state motor current this breaker can carry without tripping. The magnetic trip at 74 A ensures the breaker opens instantly on short-circuit, but allows normal motor starting inrush. Suitable for motors up to 1.5 kW at 400 V or 3 kW at 690 V. Electrical durability is 100,000 cycles at AC-3 415 V, mechanical 100,000 cycles.

Frequently asked questions

What is the rated current and magnetic trip of the GV2LE08?

The GV2LE08 is rated 4 A continuous and has a fixed magnetic trip set at 74 A for short-circuit protection.

What standards does the GV2LE08 comply with?

It complies with IEC 60947-2 (circuit-breakers), IEC 60947-4-1 (motor-starters), UL 60947-4-1, and CSA C22.2 No 60947-4-1.

What color is the GV2LE08 housing?

Dark grey.
