Schneider Electric GV3L736

Schneider GV3L736 TeSys Deca Motor Circuit Breaker, 73 A

MPNGV3L736
Obsolete

Schneider Electric TeSys Deca motor circuit breaker, GV3L736, 3-pole, 73 A rated current, magnetic trip 1120 A, 65 kA breaking capacity at 230 V, IP20, dark grey.

$468.00Ref. price · indicative, final on quote
Schneider Electric GV3L736 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

GV3L736 key specifications
ParameterValue
Control typeRotary handle
Network typeAC
Product or component typeMotor circuit breaker
Climatic withstandIACS E10
Voltage690 V AC 50/60 Hz IEC 60947-2
[Ue] rated operational voltage690 V AC 50/60 Hz IEC 60947-2
[Uimp] rated impulse withstand voltage6 kV IEC 60947-2
Breaking capacity65 kA Icu 230/240 V AC 50/60 Hz 50 kA Icu 400/415 V AC 50/60 Hz 50 kA Icu 440 V AC 50/60 Hz 12 kA Icu 500 V AC 50/60 Hz 6 kA Icu 690 V AC 50/60 Hz
Line rated current73 A
Magnetic tripping current1120 A
[Ith] conventional free air thermal current73 A IEC 60947-2
[Ics] rated service short-circuit breaking capacity100 % 230/240 V AC 50/60 Hz 60 % 400/415 V AC 50/60 Hz 60 % 440 V AC 50/60 Hz 50 % 500 V AC 50/60 Hz 50 % 690 V AC 50/60 Hz

All specifications

GV3L736 additional specifications
ParameterValue
Motor power37 kW 400/415 V AC 50/60 Hz 45 kW 500 V AC 50/60 Hz 55 kW 690 V AC 50/60 Hz
Power dissipation per pole8 W
Network frequency50/60 Hz IEC 60947-2
Poles description3P
Rated dutyUninterrupted IEC 60947-4-1
Utilisation categoryCategory A IEC 60947-2 AC-3 IEC 60947-4-1
IP degree of protectionIP20 IEC 60529
Mounting positionHorizontal Vertical
Connection pitch0.7 in (17.5 mm) without spreaders
Operating altitude9842.52 ft (3000 m)
ColorDark grey
Depth5.4 in (136 mm)
Width2.2 in (55 mm)
Height5.2 in (132 mm)
Electrical durability20000 cycles AC-3 415 V In
Mechanical durability50000 cycles
StandardsEN/IEC 60947-2 EN/IEC 60947-4-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 IEC/EN 60335-1:Clause 30.2 IEC/EN 60335-2-40:Annex JJ
RangeTeSys Deca
CategoryUS10I1122366
Fixing mode35 mm symmetrical DIN rail clipped Panel screwed with 3 x M4 screws)
Fire resistance1760 °F (960 °C) IEC 60695-2-11
Device short nameGV3L
Tightening torque53.1 lbf.in (6 N.m) lugs-ring terminals
Device applicationMotor protection
Trip unit technologyMagnetic
Mechanical robustnessShocks 5 Gn for 11 ms contactor open Shocks 30 Gn for 11 ms contactor closed Vibrations 4 Gn, 5...300 Hz
Suitability for isolationYes IEC 60947-1
Ambient air temperature for storage-40...176 °F (-40...80 °C)
Ambient air temperature for operation-4...140 °F (-20...60 °C)

Product details

Motor Protection Specifications

The GV3L736 is a motor circuit breaker from the TeSys Deca range. Rated 73 A, magnetic trip set at 1120 A. Breaking capacity reaches 65 kA at 230/240 V AC and 50 kA at 400/415 V AC, so it stands up to high fault currents in industrial panels without requiring upstream fuses.

Connection pitch is 17.5 mm without spreaders. Lug torque at 53.1 lbf·in (6 N·m). IP20 finger protection. Ambient storage range -40 to 80 °C, and it withstands 5 Gn shocks (open) and 30 Gn (closed) — tough enough for transport and machine vibration.

Compliance coverage includes EN/IEC 60947-2, 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, and IEC/EN 60335 series — covering motor protection, isolation, and appliance safety requirements.

Frequently asked questions

What compliance standards does the GV3L736 meet?

It is listed under EN/IEC 60947-2, EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, and IEC/EN 60335-1 Clause 30.2 / 60335-2-40 Annex JJ — covering motor circuit protection, isolation, and fire resistance.
