Schneider Electric GV3ME14 — Miniature Circuit Breakers (MCB)

Schneider Electric GV3ME14

MPNGV3ME14
Obsolete

motor circuit breaker GV3-ME - 6..10 A - screw clamp terminal- thermomagnetic tr

$995.98Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

GV3ME14 — Identification
ParameterValue
Product nameTeSys GV3
Product rangeTeSys
Product/component typeCircuit breaker
Device applicationMotor
GV3ME14 — Ratings
ParameterValue
Poles configuration3P
Breaking capacity100 kA Icu at 230...240 V AC 50/60 Hz conforming to IEC 60947-2 15 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 10 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 4 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 2 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2
Rated operational voltage (Ue)690 V AC 50/60 Hz conforming to IEC 60947-2 600 V AC 50/60 Hz conforming to UL 508 600 V AC 50/60 Hz conforming to CSA C22.2 No 14
Rated insulation voltage (Ui)690 V conforming to IEC 60947-2
Rated impulse withstand voltage (Uimp)6 kV conforming to IEC 60947-2
Network type (AC/DC)AC
Network frequency50/60 Hz conforming to IEC 60947-4-1 50/60 Hz conforming to UL 50/60 Hz conforming to CSA
Utilisation categoryCategory A conforming to IEC 60947-2 AC-3 conforming to IEC 60947-4-1
GV3ME14 — Protection
ParameterValue
Trip unit technologyThermal-magnetic
Electrical durability (cycles)30000 cycles for AC-3 at 440 V In/2
Mechanical durability (cycles)30000 cycles
GV3ME14 — Mechanical
ParameterValue
Mounting supportPlate Rail
Mounting modeFixed
Control typePush-button
Terminal connection typePower circuit: screw clamp terminal 1 cable(s) 2.5...35 mm²solid Power circuit: screw clamp terminal 1 cable(s) 2.5 mm²flexible without cable end Power circuit: screw clamp terminal 2 cable(s) 16 mm²flexible with cable end
Terminal tightening torque5 N.m - on EverLink BTR screw connectors - cable 2.5...16 mm² 5 N.m - on EverLink BTR screw connectors - cable 2.5...3.5 mm²
Width61 mm
Height120 mm
Depth113 mm
GV3ME14 — Environmental
ParameterValue
Operating ambient temperature-20...40 °C in enclosure -20...60 °C open mounted
Storage ambient temperature-40...80 °C
IP degree of protectionIP20 conforming to IEC 60529 (open mounted) IP55 conforming to IEC 60529 (in enclosure)
GV3ME14 — Approvals
ParameterValue
StandardsIEC 60947-2 IEC 60947-4-1 BS EN DIN EN 60947-2 DIN EN 60947-4-1 EN 60947-2 EN 60947-4-1 NF EN
GV3ME14 — Electrical
ParameterValue
[Ics] rated service short-circuit breaking capacity100 % at 230...240 V AC 50/60 Hz conforming to IEC 60947-2 50 % at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 60 % at 440 V AC 50/60 Hz conforming to IEC 60947-2 100 % at 500 V AC 50/60 Hz conforming to IEC 60947-2 100 % at 690 V AC 50/60 Hz conforming to IEC 60947-2
MPN
GV3ME14
