Schneider Electric GV4PB03N

Schneider GV4PB03N TeSys Deca Motor Circuit Breaker, 3.5 A

MPNGV4PB03N
Active

Schneider Electric TeSys Deca GV4PB03N, motor circuit breaker, 3.5 A rated current, 3 poles, thermal-magnetic electronic trip, UL 489 / IEC 60947-2/4-1.

$545.00Ref. price · indicative, final on quote
Schneider Electric GV4PB03N datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

GV4PB03N key specifications
ParameterValue
Control typeToggle
Range of productTeSys GV4
Product or component typeMotor circuit breaker
Climatic withstandIACS E10
Voltage800 V AC 50/60 Hz IEC 60947-2
[Ue] rated operational voltage690 V AC 50/60 Hz IEC 60947-2 600Y/347 V AC 60 Hz UL 489
[Uimp] rated impulse withstand voltage8 kV IEC 60947-2
Breaking capacity65 kA SCCR 240 V AC 60 Hz UL 489 35 kA SCCR 480Y/277 V AC 60 Hz UL 489 18 kA SCCR 600Y/347 V AC 60 Hz UL 489 100 kA Icu 220/240 V AC 50/60 Hz IEC 60947-2 50 kA Icu 380/415 V AC 50/60 Hz IEC 60947-2 50 kA Icu 440 V AC 50/60 Hz IEC 60947-2 25 kA Icu 500 V AC 50/60 Hz IEC 60947-2 15 kA Icu 525 V AC 50/60 Hz IEC 60947-2 8 kA Icu 660/690 V AC 50/60 Hz IEC 60947-2
Line rated current3.5 A
Magnetic tripping current60 A
[Ith] conventional free air thermal current115 A IEC 60947-4-1
[Ics] rated service short-circuit breaking capacity100 % 220/240 V AC 50/60 Hz IEC 60947-2 100 % 380/415 V AC 50/60 Hz IEC 60947-2 100 % 440 V AC 50/60 Hz IEC 60947-2 100 % 500 V AC 50/60 Hz IEC 60947-2 100 % 525 V AC 50/60 Hz IEC 60947-2 25 % 660/690 V AC 50/60 Hz IEC 60947-2

All specifications

GV4PB03N additional specifications
ParameterValue
Power dissipation per pole4.6 W
Poles description3P
Phase failure sensitivityYes IEC 60947-4-1
Rated dutyContinuous IEC 60947-4-1
Utilisation categoryCategory A IEC 60947-2 AC-3 IEC 60947-4-1
IK degree of protectionIK07 IEC 62262
IP degree of protectionIP40 IEC 60529
Connections - terminalsEverLink BTR screw connectors top) 1 0.002...0.1 in² (1.5...70 mm²) - rigid EverLink BTR screw connectors top) 1 0.002...0.08 in² (1.5...50 mm²) - flexible EverLink BTR screw connectors bottom) 1 0.004...0.1 in² (2.5...95 mm²) - rigid EverLink BTR screw connectors bottom) 1 0.004...0.1 in² (2.5...70 mm²) - flexible
Pollution degree3
Operating altitude5000 m
ColorGray RAL 7016)
Depth4.6 in (116 mm)
Width3.2 in (81 mm)
Height6.7 in (171 mm)
Electrical durability40000 cycles AC-3 440 V In/2 40000 cycles AC-3 440 V In
Mechanical durability40000 cycles
StandardsEN/IEC 60947-1 EN/IEC 60947-2 EN/IEC 60947-4-1 UL 489 CSA C22.2 No 5
RangeTeSys Deca
CategoryUS10I1122365
Fire resistance1760 °F (960 °C) IEC 60695-2-11
Device short nameGV4PB
Tightening torque79.7 lbf.in (9 N.m) 0.02...0.1 in² (16...95 mm²) 44.3 lbf.in (5 N.m) 0.002...0.02 in² (1.5...10 mm²)
Device applicationMotor protection
Operating positionAny position
Trip unit technologyThermal-magnetic Electronic
Mechanical robustnessVibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6 Vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6 Shocks 15 gn 11 ms IEC 60068-2-27
Maximum operating rate25 cyc/h
Suitability for isolationYes IEC 60947-1
Ambient air temperature for storage-58...185 °F (-50...85 °C)
Ambient air temperature for operation-13...158 °F (-25...70 °C)

Product details

The Schneider GV4PB03N is a 3.5 A, 3-pole motor circuit breaker from the TeSys GV4 family (TeSys Deca range). It combines thermal-magnetic and electronic trip technology for motor protection in both UL and IEC panels. Rated operational voltage goes to 690 V AC and it carries a 65 kA SCCR at 240 V AC (UL 489) and 100 kA Icu at 220/240 V AC (IEC 60947-2). The case is Gray RAL 7016 with IP40 protection and IK07 impact resistance.

Mounting and wiring integration

Dimensions: 171 mm high, 81 mm wide, 116 mm deep. Accepts any mounting orientation. Top terminals accept 1.5–70 mm² rigid or 1.5–50 mm² flexible; bottom terminals accept 2.5–95 mm² rigid or 2.5–70 mm² flexible. EverLink BTR screw connectors – tighten to 9 N·m (79.7 lbf·in) for the main power terminals and 5 N·m for the control/tap terminals. Power dissipation per pole is 4.6 W. Rated for continuous duty, maximum operating rate is 25 cyc/h.

Certified to UL 489, CSA C22.2 No 5, EN/IEC 60947-1/2/4-1. Fire resistance rated at 960 °C (1760 °F) per IEC 60695-2-11. Pollution degree 3. Climatic withstand per IACS. The product is suitable for isolation and meets phase failure sensitivity requirements.

Frequently asked questions

What is the color of the GV4PB03N?

The breaker housing is Gray RAL 7016.

What is the depth of the GV4PB03N?

Depth is 4.6 inches (116 mm).

What compliance standards does the GV4PB03N meet?

It complies with UL 489, CSA C22.2 No 5, EN/IEC 60947-1, EN/IEC 60947-2, and EN/IEC 60947-4-1. Also meets fire resistance at 960 °C and pollution degree 3.
