The GV4PE80N6 is a 3-pole motor circuit breaker from the TeSys Deca range, rated 80 A continuous for AC-3 motor protection per IEC 60947-4-1. Its trip unit merges thermal-magnetic and electronic elements, providing phase-failure sensitivity per IEC 60947-4-1.
Lifecycle stage is 'current' — active in production.
With an interrupting capacity of 100 kA at 240 V AC (IEC 60947-2) and 50 kA at 415 V, the GV4PE80N6 provides substantial SCCR headroom for most industrial distribution panels — the 100 kA figure at 240 V is the high end for a 3-pole motor circuit breaker in this frame.
Dimensions: width 81 mm, depth 116 mm, height 155 mm. IP40 enclosure protection, IK07 impact resistance. Operating position any; altitude 5000 m max. Connection via lugs/ring terminals. Tightening torque 9 N·m for conductors up to 95 mm² (0.02–0.1 in²), 5 N·m for control wires 1.5–10 mm² — the 79.7 lbf·in value for the main power circuit is within spec.
Mechanical endurance: 40,000 operations. Electrical endurance at AC-3 440 V: 14,000 cycles at In/2, 7,000 cycles at In. Maximum operating rate 25 cycles per hour.
