Schneider Electric GV4PEM02N

Schneider Electric GV4PEM02N TeSys GV4 Motor Circuit Breaker

MPNGV4PEM02N
Active

Schneider Electric TeSys GV4 motor circuit breaker, GV4PEM02N, 3-pole, 2 A line rated current, thermal-magnetic and electronic trip, breaking capacity up to 100 kA at 240 V.

$935.00 – $1,350.00Ref. price · indicative, final on quote
Schneider Electric GV4PEM02N datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

GV4PEM02N key specifications
ParameterValue
Control typeToggle
Range of productTeSys GV4
Product or component typeMotor circuit breaker
Climatic withstandIACS E10
Voltage800 V AC 50/60 Hz IEC 60947-2
[Ue] rated operational voltage690 V AC 50/60 Hz IEC 60947-2
[Uimp] rated impulse withstand voltage8 kV IEC 60947-2
Breaking capacity100 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2 50 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2 50 kA Icu 440 V AC 50/60 Hz IEC 60947-2 15 kA Icu 525 V AC 50/60 Hz IEC 60947-2 65 kA 208Y/120 V AC 50/60 Hz UL 60947 65 kA 240 V AC 50/60 Hz UL 60947 35 kA 480Y/277 V AC 50/60 Hz UL 60947 8 kA Icu 660...690 V AC 50/60 Hz IEC 60947-2 25 kA Icu 500 V AC 50/60 Hz IEC 60947-2 18 kA 600Y/347 V AC 50/60 Hz UL 60947
Line rated current2 A
Magnetic tripping current34 A
[Ith] conventional free air thermal current115 A IEC 60947-4-1
Motor power0.25 kW 400...415 V AC 50/60 Hz 0.37 kW 400...415 V AC 50/60 Hz 0.55 kW 400...415 V AC 50/60 Hz 0.75 kW 400...415 V AC 50/60 Hz 0.37 kW 500 V AC 50/60 Hz 0.55 kW 500 V AC 50/60 Hz 0.75 kW 500 V AC 50/60 Hz 1.1 kW 500 V AC 50/60 Hz 0.55 kW 660...690 V AC 50/60 Hz 0.75 kW 660...690 V AC 50/60 Hz 1.1 kW 660...690 V AC 50/60 Hz 1.5 kW 660...690 V AC 50/60 Hz

All specifications

GV4PEM02N additional specifications
ParameterValue
Power dissipation per pole4.6 W
Poles description3P
Phase failure sensitivityYes IEC 60947-4-1
Rated dutyContinuous IEC 60947-4-1
Utilisation categoryCategory A IEC 60947-2 AC-3 IEC 60947-4-1
IK degree of protectionIK07 IEC 62262
IP degree of protectionIP40 IEC 60529
Connections - terminalsEverLink BTR screw connectors top) 1 0.002...0.1 in² (1.5...70 mm²) - solid EverLink BTR screw connectors top) 1 0.002...0.08 in² (1.5...50 mm²) - flexible EverLink BTR screw connectors bottom) 1 0.004...0.1 in² (2.5...95 mm²) - solid EverLink BTR screw connectors bottom) 1 0.004...0.1 in² (2.5...70 mm²) - flexible
Pollution degree3
Operating altitude5000 m
ColorGray RAL 7016)
Depth4.6 in (116 mm)
Width3.2 in (81 mm)
Height6.1 in (155 mm)
Electrical durability40000 cycles AC-3 440 V In/2 40000 cycles AC-3 440 V In
Mechanical durability40000 cycles
StandardsCSA C22.2 No 60947-4-1 UL 60947-4-1 EN/IEC 60947-4-1 EN/IEC 60947-2
RangeTeSys Deca
CategoryUS10I1122365
Fire resistance1760 °F (960 °C) IEC 60695-2-11
Device short nameGV4PEM
Tightening torque79.7 lbf.in (9 N.m) 0.02...0.1 in² (16...95 mm²) 44.3 lbf.in (5 N.m) 0.002...0.02 in² (1.5...10 mm²)
Device applicationMotor protection
Operating positionAny position
Trip unit technologyThermal-magnetic Electronic
Mechanical robustnessVibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6 Vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6 Shocks 15 gn 11 ms IEC 60068-2-27
Maximum operating rate25 cyc/h
Suitability for isolationYes IEC 60947-1
Ambient air temperature for storage-58...185 °F (-50...85 °C)
Ambient air temperature for operation-13...158 °F (-25...70 °C)

Product details

The Schneider Electric GV4PEM02N is a TeSys GV4 motor circuit breaker rated for 2 A line current, protecting motors in the 0.25–1.5 kW range depending on the supply voltage (400–690 V).

At 240 V AC, the GV4PEM02N delivers 100 kA Icu (IEC 60947-2) — enough for most industrial panel SCCR requirements. At 480Y/277 V UL 60947 it still holds 35 kA, and at 415 V IEC 50 kA. That coverage means this breaker can sit ahead of smaller contactors without needing a separate current-limiting upstream device in many high-fault installations. The category A utilization (IEC 60947-2) indicates it is not intended for selective coordination downstream of another breaker — plan for cascade or backup protection if selectivity is required.

Connections and mounting

EverLink BTR screw terminals on both top and bottom accept up to 95 mm² solid or 70 mm² flexible on the load side. Tightening torque is 9 N·m for the main power terminals and 5 N·m for the control/auxiliary terminals. The unit fits a 81 mm wide footprint (3.2 in), mounts in any position, and is rated IP40 with IK07 impact resistance — fine for a standard enclosure but not for washdown areas. Operating altitude rated to 5000 m, so it works at high-elevation sites without derating.

Frequently asked questions

What certifications does the GV4PEM02N carry?

It is certified to CSA C22.2 No 60947-4-1, UL 60947-4-1, EN/IEC 60947-4-1, and EN/IEC 60947-2.

What is the breaking capacity of the GV4PEM02N at 480 V?

Under UL 60947 at 480Y/277 V, the breaking capacity is 35 kA. Under IEC at 440 V it is 50 kA.
