Schneider Electric GVAE113
MPNGVAE113
Obsolete
MANUAL STARTER AUX|SQD GVAE113 MANUAL STARTER AUX
$3.61Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Protection type | GG fuse 10 A GB2CB06 circuit breaker 10 A |
| Product or component type | Auxiliary contact block |
| Minimum switching voltage | 17 V |
| Voltage | 300 V UL 508 300 V CSA C22.2 No 14 250 V IEC 60947-1 |
| [Ue] rated operational voltage | 24...240 V AC 24...60 V DC |
| Minimum switching current | 5 mA |
| [Ith] conventional free air thermal current | 2.5 A |
| Rated operational power in | 15 W 48 V DC-13 100000 cycles 24 W 24 V DC-13 100000 cycles 9 W 60 V DC-13 100000 cycles |
| Pole contact composition | 1 NO + 1 NC |
| Mounting location | Front side |
| Color | Dark grey |
| Depth | 1.2 in (31.5 mm) |
All specifications
| Parameter | Value |
|---|---|
| Width | 1.8 in (44.5 mm) |
| Height | 0.5 in (13 mm) |
| Mechanical durability | 100000 cycles |
| Range | TeSys TeSys Deca |
| Category | US10I1122367 |
| Quantity per set | Set of 10 |
| Device short name | GVAE |
| Environmental characteristic | Normal environment |
MPN
GVAE113
