Schneider Electric Harmony iPC HMIYMINCAN1 CANopen/CANBus interface, Mini PCIe full-size, 2 female SUB-D 9, 1 Mbit/s, 16 MHz, 6.6 ft (2 m) cable, 400 mA 5 V DC, discontinued.
| Parameter | Value |
|---|---|
| Range of product | Harmony iPC |
| Product or component type | CANopen/CANBus interface |
| Integrated connection type | Mini PCIe full-size 2 female SUB-D 9 1 Mbit/s 16 MHz 6.6 ft (2 m) |
| Input current | 400 mA 5 V DC |
| Relative humidity | 5...95 % non-condensing |
| Depth | 1.5 in (38.2 mm) |
| Width | 3.0 in (76 mm) |
| Height | 3.2 in (81 mm) |
| Category | US10MC222574 |
| Accessory (separate part category) | Connection accessory |
| Ambient air temperature for storage | -4...140 °F (-20...60 °C) |
| Ambient air temperature for operation | -40...185 °F (-40...85 °C) |
The HMIYMINCAN1 is a CANopen/CANBus interface module for the Schneider Harmony iPC range, fitting a Mini PCIe full-size slot and providing two female SUB-D 9 connectors for 1 Mbit/s bus communication. It draws 400 mA from a 5 V DC supply and ships with a 6.6 ft (2 m) cable; the part is a connection accessory, not a standalone controller.
Schneider lists the HMIYMINCAN1 as discontinued; no official successor is named. An RFQ confirms available quantity and lead time.
