Schneider HMIYMINIO1 Square D Circuit Breaker Undervoltage Trip 380 Ac/Dc — now discontinued, supplied from remaining surplus and broker stock.
| Parameter | Value |
|---|---|
| Range of product | Harmony iPC |
| Product or component type | Digital input/output cards |
| Integrated connection type | Mini PCIe full-size screw terminals 6.6 ft (2 m) |
| Input voltage | 0...3 V DC 10...30 V DC |
| Output voltage | 5...30 V DC |
| Input current | 2.97 mA 10 V DC 6.35 mA 20 V DC |
| Relative humidity | 5...95 % non-condensing |
| Depth | 1.4 in (36.5 mm) |
| Width | 3.0 in (76 mm) |
| Height | 3.2 in (81 mm) |
| Category | US10MC222574 |
| Accessory (separate part category) | Connection accessory |
| Ambient air temperature for storage | -40...185 °F (-40...85 °C) |
| Ambient air temperature for operation | -4...140 °F (-20...60 °C) |
The HMIYMINIO1 is a digital I/O expansion card for the Schneider Harmony iPC range, providing 16 digital inputs and 8 digital outputs on a Mini PCIe full-size interface with screw-terminal connection. Input current draws 2.97 mA at 10 V DC and 6.35 mA at 20 V DC; output voltage range is 5 to 30 V DC. The card measures 76.2 mm wide by 81.28 mm tall by 35.56 mm deep.
Schneider discontinued the HMIYMINIO1 on 2023-10-09. Send an RFQ to confirm availability and lead time.
