Schneider Electric ILM62DB4A000
MPNILM62DB4A000
Active
DISTRIBUTION BOX WITH 1 INPUT AND 4 OUTPUTS|DISTRIBUTION BOX WITH 1 INPUT AND 4 OUTPUTS
$1,315.00Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Type of cooling | Natural convection |
| Range of product | PacDrive 3 |
| Product or component type | Distribution block |
| Supply voltage | 250...700 V |
| Coil voltage | 24 V DC - 20...25 %) |
| Input current | 20 A |
| IP degree of protection | IP65 |
| Physical interface | SERCOS III 100 Mbit/s |
| Pollution degree | 2 IEC 61800-5-1 |
| Depth | 6.0 in (151.4 mm) |
| Width | 9.06 in (230 mm) |
| Height | 3.7 in (94 mm) |
| Material | Polycarbonate |
| Category | US1PC5218351 |
| Device short name | ILM |
| Overvoltage category | Class 3 conforming to IEC 61800-5-1 |
MPN
ILM62DB4A000
