Schneider Electric LA4DLB
MPNLA4DLB
Active
TeSys D - interface amplifier module - relay + override - 24 V DC / 250 V AC
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Technology type | Electromechanical + override |
| Product or component type | Interface module |
| Supply voltage | 24 V DC |
| Voltage state 0 guaranteed | < 2.4 V |
| Voltage state 1 guaranteed | 17 V |
| Voltage | 250 V - control circuit IEC 60947-5-1 |
| [Ue] rated operational voltage | Control circuit 24...250 V AC |
| Current consumption | 25 mA 68 °F (20 °C) |
| Current state 0 guaranteed | <= 2 mA |
| Poles description | 3P 4P |
| IP degree of protection | IP2X conforming to VDE 0106 |
| Mounting mode | Top mounted |
All specifications
| Parameter | Value |
|---|---|
| Connections - terminals | Control circuit connector 1 0.002...0.004 in² (1...2.5 mm²)flexible with cable end Control circuit connector 1 0.002...0.004 in² (1...2.5 mm²)flexible without cable end Control circuit connector 1 0.002...0.004 in² (1...2.5 mm²)solid with cable end Control circuit connector 1 0.002...0.004 in² (1...2.5 mm²)solid without cable end Control circuit connector 2 0.002...0.004 in² (1...2.5 mm²)flexible with cable end Control circuit connector 2 0.002...0.004 in² (1...2.5 mm²)flexible without cable end Control circuit connector 2 0.002...0.004 in² (1...2.5 mm²)solid with cable end Control circuit connector 2 0.002...0.004 in² (1...2.5 mm²)solid without cable end |
| Height | 0.7 in (19 mm) |
| Electrical durability | 3 Mcycles 240 V |
| Standards | IEC 60255-5 |
| Range | TeSys |
| Category | 22341-CONTACTOR,D,K,&F ACCESS |
| Heat dissipation | 0.6 W control circuit |
| Local signalling | LED indicator |
| Device short name | LA4D |
| Protective treatment | TH IEC 60068 |
| Immunity to microbreaks | 4 ms |
| Ambient air temperature for storage | -40...176 °F (-40...80 °C) |
| Ambient air temperature for operation | -13...131 °F (-25...55 °C) |
MPN
LA4DLB
