The Schneider LA9GRD01 is a function module that sits on top of a TeSys contactor and gives you a remote alarm signal through a single dry NC contact. That NC contact is rated for the 5 A free-air thermal current, so it can drive a relay or a PLC input directly—but watch the load curve on inductive coils. IP20 keeps dust off the terminals, though I still blow out the panel annually.
Schneider LA9GRD01 TeSys Function Module, 5A NC Contact, IP2
MPNLA9GRD01
Active
Schneider Electric TeSys Function Module LA9GRD01, 1 NC auxiliary contact, 5 A conventional free air thermal current, IP20, 50 mm depth.
$169.84Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Product or component type | Function module |
| [Ith] conventional free air thermal current | 5 A |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Mounting location | Top |
| Connection pitch | 0.20 in (5.08 mm) |
| Pollution degree | 3 IEC 60947-1 |
| Operating altitude | 9842.52 ft (3000 m) without derating 5000 m with derating factor |
| Depth | 2.0 in (50 mm) |
| Width | 1.2 in (30 mm) |
| Height | 3.6 in (91.5 mm) |
| Standards | EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-5-1 CSA C22.2 No 60947-5-1 JIS C8201-4-1 JIS C8201-5-1 IEC 60335-1:Clause 30.2 IEC 60335-2-40:Annex JJ UL 60335-1 UL 60335-2-40:Annex JJ |
| Range | TeSys |
All specifications
| Parameter | Value |
|---|---|
| Category | US10I1222328 |
| Quantity per set | Set of 1 |
| Device short name | LA9G |
| Main function available | Remote alarm |
| Auxiliary contact composition | 1 NC |
| Ambient air temperature for storage | -76...176 °F (-60...80 °C) |
| Ambient air temperature for operation | -13...140 °F (-25...60 °C) |
Product details
Frequently asked questions
What compliance documentation does this module carry?
It meets EN/IEC 60947-4-1 and -5-1, UL 60947-5-1, CSA C22.2 No 60947-5-1, JIS C8201-4-1 and -5-1, plus IEC 60335-1 and -2-40 annex JJ for appliance safety.
What are the key electrical ratings?
One NC auxiliary contact rated 5 A conventional free-air thermal current. The contact is rated per the IEC/UL standards above, so you can switch pilot-duty loads without concern.
