Schneider LC1K0601P72TQ Contactor
MPNLC1K0601P72TQ
Obsolete
Contactor, 3 Poles, 3NO, 6A @ 690V, 230V Coil
$51.33Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Product or component type | Contactor |
| Minimum switching voltage | 17 V for control circuit |
| Control circuit voltage limits | Operational: 0.8...1.15 Uc at 50/60 Hz (at Drop-out: >= 0.20 Uc at 50/60 Hz (at <50 °C) |
| [Ue] rated operational voltage | Power circuit: Signalling circuit: 10 MOhm for control circuit |
| Minimum switching current | 5 mA for control circuit |
| Inrush power in | 30 VA (at 20 °C) |
| Power pole contact composition | 3 NO |
| Hold-in power consumption in | 4.5 VA 50/60 Hz (at 20 °C) |
| Poles description | 3P |
| Utilisation category | AC-3 AC-3e AC-4 |
| Mounting support | Plate Rail |
| Connections - terminals | Screw clamp terminals 1 cable(s) 1.5...4 mm²solid Screw clamp terminals 1 cable(s) 0.75...4 mm²flexible without cable end Screw clamp terminals 1 cable(s) 0.34...2.5 mm²flexible with cable end Screw clamp terminals 2 cable(s) 1.5...4 mm²solid Screw clamp terminals 2 cable(s) 0.75...4 mm²flexible without cable end Screw clamp terminals 2 cable(s) 0.34...1.5 mm²flexible with cable end |
All specifications
| Parameter | Value |
|---|---|
| Operating altitude | 2000 m without derating |
| Depth | 57 mm |
| Width | 45 mm |
| Height | 58 mm |
| Electrical durability | 1.3 Mcycles 6 A AC-3 at Ue 1.3 Mcycles 6 A AC-3e at Ue 0.05 Mcycles 36 A AC-4 at Ue <= 440 V |
| Mechanical durability | 10 Mcycles |
| Standards | EN/IEC 60947-4-1 GB/T 14048.4 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 |
| Range | TeSys |
| Operating time | 10...20 ms coil de-energisation and NO opening 15...25 ms coil de-energisation and NC opening 10...20 ms between energisation of coil and closing of NO contact 5...15 ms coil energisation and NC opening |
| Coil technology | With integral suppression device |
| Fire resistance | 850 °C conforming to IEC 60695-2-1 |
| Flame retardance | Class C2 conforming to NF F 16-101 Class C2 conforming to NF F 16-102 V1 conforming to UL 94 |
| Device short name | LC1K |
| Contactor application | Motor control |
| Maximum operating rate | 3600 cyc/h |
| Safety reliability level | B10d = 1369863 cycles contactor with nominal load conforming to EN/ISO 13849-1 B10d = 20000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1 |
| Ambient air temperature for storage | -50...80 °C |
