Overview
The LC2D32KUE is a Schneider TeSys Deca reversing contactor rated for 32 A switching current on a 3-pole frame, energized by a 100 V coil. It ships preassembled with the reversing power busbar, saving panel build time on motor-reversing circuits. Rated for both AC-1 (resistive) and AC-3 (motor) duty, it carries CCC, CSA, UL, DNV-GL, EAC, UKCA, and KC approvals, covering most global panel acceptance requirements.
Compared to the LC2D38KUE, the LC2D32KUE switches 32 A versus 38 A and uses a 100 V coil versus the LC2D38KUE's unspecified coil voltage. The LC2D38KUE carries a single electrical life cycle rating, while the LC2D32KUE lists 2 electrical life cycles, indicating a longer endurance for the same switching duty.
