Schneider Electric LC2K06105M7

Schneider LC2K06105M7 TeSys K reversing contactor, 3P, 6A, 220-230VAC coil

MPNLC2K06105M7
Active

Schneider TeSys K reversing contactor, order code LC2K06105M7, 3 poles, 6 A, AC-3/AC-4 440V, 1 NO, 220-230 VAC coil, solder pins, IP20.

$115.56Ref. price · indicative, final on quote
Schneider Electric LC2K06105M7 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

LC2K06105M7 key specifications
ParameterValue
Product or component typeReversing contactor
[Ue] rated operational voltagePower circuit 690 V AC 50/60 Hz Signalling circuit 10 MOhm for signalling circuit
Power pole contact composition3 NO
Poles description3P
Utilisation categoryAC-4 AC-3
IP degree of protectionIP20 VDE 0106
Operating altitude6561.68 ft (2000 m) without derating
Depth2.2 in (57 mm)
Width3.5 in (90 mm)
Height2.3 in (58 mm)
RangeTeSys
CategoryUS10I1222327

All specifications

LC2K06105M7 additional specifications
ParameterValue
Flame retardanceV1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
Device short nameLC2K
Device applicationControl
Device presentationPreassembled with reversing power busbar
Protective treatmentTC IEC 60068 TC DIN 50016
Contactor applicationMotor control
Mechanical robustnessShocks contactor closed, on X axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Y axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Z axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on X axis6 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Y axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Z axis10 Gn for 11 ms IEC 60068-2-27 Vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 Vibrations contactor opened2 Gn, 5...300 Hz IEC 60068-2-6
Ambient air temperature for storage-58...176 °F (-50...80 °C)
Ambient air temperature for operation-13...122 °F (-25...50 °C)

Product details

Overview

The LC2K06105M7 is a Schneider TeSys K reversing contactor, 3-pole, rated 6 A in AC-3 at 440 V, with a 220-230 VAC coil and one normally open auxiliary contact.

This reversing contactor mechanically interlock two contactors in a single package, allowing forward/reverse motor control without external interlocks. The AC-3 utilization category covers squirrel-cage motor starting and switching off during running; Rated for 690 V insulation voltage, the 6 A AC-3 rating at 440 V defines the maximum motor FLA it can switch. The 220-230 VAC coil draws its nominal hold power from a standard control transformer.

MPN
LC2K06105M7
