It's rated for AC-3 and AC-4 duty, meaning it's built for starting and stopping squirrel-cage motors, including plugging and inching. The motor current rating is 6 A at 440 V AC in AC-3, which covers small three-phase motors up to about 2.2 kW at 400 V.
Schneider TeSys K LC2K0610K7 reversing contactor, 6A AC-3, 1
MPNLC2K0610K7
Obsolete
Schneider Electric TeSys K reversing contactor, LC2K0610K7, 3P, AC-3 6A ≤440V, 1NO auxiliary, 100V AC coil, preassembled with reversing power busbar.
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Product / component type | Reversing contactor |
| Series / range | TeSys |
| Application | Motor control |
| Parameter | Value |
|---|---|
| Rated operational voltage (Ue) | Power circuit: 690 V AC 50/60 Hz Signalling circuit: 10 MOhm for signalling circuit |
| Utilisation category | AC-3 AC-4 |
| Parameter | Value |
|---|---|
| Pole configuration | 3P |
| Parameter | Value |
|---|---|
| IP degree of protection | IP20 conforming to VDE 0106 |
| Operating altitude | 2000 m without derating |
| Mechanical robustness | Shocks contactor closed, on X axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor closed, on Y axis: 15 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor closed, on Z axis: 15 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor opened, on X axis: 6 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor opened, on Y axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor opened, on Z axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 Vibrations contactor closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6 Vibrations contactor opened: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| Protective treatment / pollution degree | TC conforming to IEC 60068 TC conforming to DIN 50016 |
| Flame retardance | V1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102 |
| Parameter | Value |
|---|---|
| Width | 90 mm |
| Height | 58 mm |
| Depth | 57 mm |
Product details
Frequently asked questions
What is the closest alternative to the LC2K0610K7?
There is no official successor order code listed. For a new design, you would select a current TeSys K or TeSys Deca reversing contactor with a 100 V AC coil, 3 poles, and 1 NO auxiliary contact. The exact fit depends on your panel layout and busbar arrangement.
What are the key electrical ratings?
Rated operational voltage 690 V AC on the power circuit. AC-3 motor current 6 A at ≤440 V. Coil 100 V AC 50/60 Hz. One normally open auxiliary contact.
MPN
LC2K0610K7
