Schneider Electric LC2K1210G7

Schneider LC2K1210G7 TeSys K reversing contactor, 3P, 12 A AC-3, 120 VAC coil

MPNLC2K1210G7
Obsolete

Schneider TeSys K LC2K1210G7 reversing contactor, 3 poles, 12 A AC-3, 20 A AC-1, 120 VAC coil, 1 NO aux, IP20, open enclosure, discontinued.

$88.90 – $258.27Ref. price · indicative, final on quote
Schneider Electric LC2K1210G7 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

LC2K1210G7 key specifications
ParameterValue
Product or component typeReversing contactor
[Ue] rated operational voltagePower circuit 690 V AC 50/60 Hz Signalling circuit 10 MOhm for signalling circuit
Power pole contact composition3 NO
Poles description3P
Utilisation categoryAC-4 AC-1 AC-3 AC-3e
IP degree of protectionIP20 VDE 0106
Operating altitude6561.68 ft (2000 m) without derating
Depth2.2 in (57 mm)
Width3.5 in (90 mm)
Height2.3 in (58 mm)
RangeTeSys
CategoryUS10I1222327

All specifications

LC2K1210G7 additional specifications
ParameterValue
Flame retardanceV1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
Device short nameLC2K
Device applicationControl
Device presentationPreassembled with reversing power busbar
Protective treatmentTC IEC 60068 TC DIN 50016
Contactor applicationResistive load Motor control
Mechanical robustnessShocks contactor closed, on X axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Y axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Z axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on X axis6 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Y axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Z axis10 Gn for 11 ms IEC 60068-2-27 Vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 Vibrations contactor opened2 Gn, 5...300 Hz IEC 60068-2-6
Ambient air temperature for storage-58...176 °F (-50...80 °C)
Ambient air temperature for operation-13...122 °F (-25...50 °C)

Product details

Overview

The LC2K1210G7 is a Schneider TeSys K reversing contactor, 3-pole, rated 12 A in AC-3 (inductive) and 20 A in AC-1 (resistive), with a 120 VAC coil and one normally-open auxiliary contact. It comes preassembled with a reversing power busbar and is IP20 rated. Schneider has discontinued this part.

MPN
LC2K1210G7
