Schneider Electric TeSys K contactor, 3P, AC-3 ≤440 V 6 A, 1 NC aux., 230-240 VAC coil, active production.
| Parameter | Value |
|---|---|
| Product / component type | Contactor |
| Series / range | TeSys |
| Parameter | Value |
|---|---|
| Utilisation category | AC-3 AC-4 |
| Parameter | Value |
|---|---|
| Pole configuration | 3P |
| Parameter | Value |
|---|---|
| Flame retardance | V1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102 |
| Parameter | Value |
|---|---|
| Width | 45 mm |
| Height | 58 mm |
| Depth | 57 mm |
| Parameter | Value |
|---|---|
| Motor power | 1.5 kW at 220...230 V AC 50/60 Hz 2.2 kW at 380...415 V AC 50/60 Hz 3 kW at 440 V AC 50/60 Hz 3 kW at 480 V AC 50/60 Hz 3 kW at 500...600 V AC 50/60 Hz 3 kW at 660...690 V AC 50/60 Hz |
| Heat dissipation | 3 W |
| Range of product | TeSys K |
| Device short name | LC7K |
| Compatibility code | LC7K |
| Device application | Control |
| Pole contact composition | 3 NO |
| [Ie] rated operational current | 6 A at 10 MOhm for signalling circuit |
| [Icw] rated short-time withstand current | 90 A 50 °C - 1 s for power circuit 85 A 50 °C - 5 s for power circuit 80 A 50 °C - 10 s for power circuit 60 A 50 °C - 30 s for power circuit 45 A 50 °C - 1 min for power circuit 40 A 50 °C - 3 min for power circuit 20 A 50 °C - >= 15 min for power circuit 80 A - 1 s for signalling circuit 90 A - 500 ms for signalling circuit 110 A - 100 ms for signalling circuit |
The Schneider Electric TeSys K LC7K0601U7 is a 3-pole contactor rated for control applications in AC-3 and AC-4 utilisation categories. The coil is 230-240 VAC, 50/60 Hz.
The contactor's motor power rating varies with line voltage: 1.5 kW at 220-230 VAC, 2.2 kW at 380-415 VAC, and 3 kW at 440 V, 480 V, 500-600 V, and 660-690 VAC. This lets you size it for the actual supply on site — a 480 V line gives you the full 3 kW capability.
Motor power is 1.5 kW at 220-230 VAC, 2.2 kW at 380-415 VAC, and 3 kW at 440 V, 480 V, 500-600 V, and 660-690 VAC.
It is rated for AC-3 (squirrel-cage motor starting) and AC-4 (plugging/inching) duty.
The contactor carries UL 94 V1 flame retardance and NF F 16-101/102 Class 2 certification. Standard Schneider Electric declarations for RoHS, REACH, and CE are available for the TeSys K series.
