Schneider Electric LE1GVMEK
MPNLE1GVMEK
Obsolete
Schneider Electric LE1-GV Series Enclosure for Use with LE1 Series, 201mm Length
$36.83 – $53.40Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | TeSys |
| Product or component type | Enclosure |
| Utilisation category | AC-3 |
| IP degree of protection | IP55 |
| Cable entry number | 2 ISO20 top 2 ISO20 bottom 2 ISO25 top 2 ISO25 bottom |
| Depth | 94 mm |
| Width | 101 mm |
| Height | 201 mm |
| Material | Polycarbonate |
| Standards | IEC 60947-4-1 |
| Device short name | LE1GVME |
| Device application | Standard |
| Device composition | Contactor ordered separately Circuit-breaker ordered separately Sealing kit |
| Environmental characteristic | Standard environment |
| Ambient air temperature for operation | -5...40 °C |
MPN
LE1GVMEK
