Schneider LH26300AC Molded Case Breaker
MPNLH26300AC
Active
SQUARE D LH26300AC: MOLDED CASE CIRCUIT BREAKER 600V 300A
$5,810.00 – $9,882.48Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product or component type | Circuit breaker |
| Line rated current | 300 A |
| Magnetic hold current | 1500 A |
| Breaking capacity code | H |
| Magnetic tripping current | 3000 A |
| Poles | 2P |
| Phase connection | AC |
| Mounting mode | I-Line |
| Terminal identifier | AL400LA |
| Electrical connection | Lugs, load I-Line connection, line |
| Depth | 5.84 in (148.34 mm) |
| Width | 6 in (152.4 mm) |
All specifications
| Parameter | Value |
|---|---|
| Height | 11 in (279.4 mm) |
| Certifications | CSA UL Listed |
| Category | US10DE201040 |
| Tightening torque | 115.06 lbf.in (13 N.m) 0.07...0.5 in² (42...304 mm²) (AWG 1...600 kcmil) 115.06 lbf.in (13 N.m) 0.07...0.2 in² (42...127 mm²) (AWG 1...250 kcmil) |
| Trip unit technology | Thermal-magnetic |
| Wiring configuration | 2-wire |
| Circuit breaker application | HACR rated |
MPN
LH26300AC
