Schneider Electric LP5K12015BW3

Schneider LP5K12015BW3 TeSys K Reversing Contactor, 3P, 690V

MPNLP5K12015BW3
Active

Schneider Electric TeSys K reversing contactor, LP5K12015BW3, 3 poles, 690V AC, IP20, preassembled with reversing power busbar.

$119.09 – $279.00Ref. price · indicative, final on quote
Schneider Electric LP5K12015BW3 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

LP5K12015BW3 key specifications
ParameterValue
Product or component typeReversing contactor
[Ue] rated operational voltagePower circuit 690 V AC 50/60 Hz Signalling circuit 10 MOhm for signalling circuit
Power pole contact composition3 NO
Poles description3P
Utilisation categoryAC-3 AC-1 AC-4 AC-3e
IP degree of protectionIP20 VDE 0106
Operating altitude6561.68 ft (2000 m) without derating
Depth2.2 in (57 mm)
Width3.5 in (90 mm)
Height2.3 in (58 mm)
RangeTeSys
CategoryUS10I1222322

All specifications

LP5K12015BW3 additional specifications
ParameterValue
Flame retardanceV1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
Device short nameLP5K
Device applicationControl
Device presentationPreassembled with reversing power busbar
Protective treatmentTC IEC 60068 TC DIN 50016
Contactor applicationMotor control Resistive load
Mechanical robustnessShocks contactor closed, on Z axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Z axis10 Gn for 11 ms IEC 60068-2-27 Vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 Vibrations contactor opened2 Gn, 5...300 Hz IEC 60068-2-6 Shocks contactor opened, on X axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Y axis6 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on X axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Y axis10 Gn for 11 ms IEC 60068-2-27
Ambient air temperature for storage-58...176 °F (-50...80 °C)
Ambient air temperature for operation-13...122 °F (-25...50 °C)

Product details

The LP5K12015BW3: Rated for control and motor switching duties: AC-3, AC-4, and AC-1 utilization categories apply for 3-pole NO power contacts. IP20 finger-safe protection (VDE 0106) and V1 flame retardance (UL 94) mean it's panel-mount ready without extra guarding. Operating ambient range –25 to +50 °C suits typical plant-floor environments.

Key ratings in practice

Preassembled busbar saves three power wires and shortens panel wiring time. It's a mechanical interlock built into the reversing configuration—no external interlock relay needed. Mechanical shock ratings: 15 Gn closed, 10 Gn open along Z axis—good for high-vibration lines like conveyors or compressors.

No known pin-compatible second source in the TeSys K family. If you need an alternate, check the TeSys K catalog for a non-reversing contactor + separate mechanical interlock—but that adds panel space and wiring. This preassembled version is the drop-in choice.

Frequently asked questions

What is the depth of the LP5K12015BW3?

Depth is 2.2 in (57 mm). Width 3.5 in (90 mm), height 2.3 in (58 mm).

What product range does the LP5K12015BW3 belong to?

It is part of the TeSys K range, specifically the TeSys K reversing contactor series.

What compliance documentation is available for the LP5K12015BW3?

The contactor carries IP20 protection (VDE 0106) and flame retardance V1 per UL 94, plus NF F 16-101/102 requirements. Schneider typically provides CE, CCC, and RoHS declarations on request; check the product datasheet for full certification lists.
